LAM Research 810-802902-038 PCB assembly
Lam Research 810-802902-038
Product Overview
The Lam Research 810-802902-038 is a specialized Node 2 motherboard / PCB assembly designed for Lam Research semiconductor manufacturing equipment. Official equipment-part records define this component as “PCB ASSY, NODE 2 MB, PM, HE”, and it is cross-referenced with the associated part number 810-800256-207 in industrial component listings.
Differing from conventional PC motherboards and general-purpose industrial controllers, this board is custom-built for Lam Research’s exclusive equipment architecture. As a core node-level motherboard, it serves as a critical electronic platform to realize interconnection and collaborative operation between various supporting assemblies, including control units, communication modules, and equipment interface components.
Primarily applied for equipment maintenance and replacement, this component acts as a reliable spare part for semiconductor fabs that adopt compatible Lam Research processing tools.
Product Details
Below are the standardized core parameters and attribute information of the product:
- Manufacturer: Lam Research
- Part Number: 810-802902-038
- Product Type: PCB Assembly / Node 2 Motherboard
- Board Identification: NODE 2 MB, PM, HE
- Associated Part: 810-800256-207
- Application: Semiconductor manufacturing equipment
- Equipment Category: Process and equipment control electronics
- Revision Example: Rev C
- Typical Supply Condition: New surplus, used, refurbished, or tested
- Reported Unit Weight: Approximately 0.7 kg for one single assembly
At present, publicly available industry resources do not provide complete and reliable detailed electrical specifications for this board, including operating voltage, processor configuration, communication protocols, connector pin assignments, and environmental adaptability ratings. All relevant technical parameters must be verified against official Lam Research equipment documentation prior to formal installation and commissioning.
Node 2 Architecture
The 810-802902-038 is a core component of Lam Research’s node-based equipment architecture. The “NODE 2 MB” naming confirms its core positioning as the motherboard responsible for Node 2 assembly operation.
This node-level motherboard undertakes key electrical connection and logical scheduling functions, supporting data interaction and collaborative work among multiple equipment subsystems. According to different host tool configurations, it can be matched with the following electronic components:
- Processing and control boards
- Interface PCBAs
- Sensor circuits
- Actuator interfaces
- Communication assemblies
- Power-related electronics
- Equipment monitoring circuits
It is worth noting that the functional definition of each interface is customized for specific equipment models. Therefore, personnel must confirm connector definitions and overall system configuration before board replacement to avoid mismatching faults.
Semiconductor Manufacturing Applications
Lam Research professional semiconductor equipment is widely used in advanced wafer fabrication scenarios, which rely on highly precise and coordinated electromechanical systems to ensure stable and repeatable chip processing procedures. The 810-802902-038 motherboard is an essential maintenance spare part for compatible Lam Research equipment, applicable to the following production environments:
- Semiconductor fabrication facilities
- Wafer-processing systems
- Plasma processing equipment
- Process-control platforms
- Automated semiconductor production lines
- Equipment monitoring and control systems
This part number is continuously recorded in industrial spare part inventory systems, and all official industry listings uniformly classify it as a NODE 2 MB, PM, HE professional assembly.
Installation and Maintenance Guidelines
Lam Research equipment is equipped with multiple circuit boards with similar appearances but differentiated electrical functions. To avoid installation errors and equipment failures, strict identification and inspection procedures are required during the replacement of 810-802902-038. Maintenance personnel must complete the following operations before and after installation:
- Confirm the complete and accurate part number: 810-802902-038
- Verify the board revision, especially for existing equipment with Rev C version boards
- Confirm the matching degree of the target Lam Research equipment and Node 2 system configuration
- Compare the connector positions and cable wiring routes of the new board with the original one
- Inspect board contacts for oxidation, contamination, scratches and other mechanical damage
- Check the operating status of supporting boards and connecting cables before system power-on
- Follow standard ESD electrostatic protection specifications when handling the PCBA
- Implement equipment-specific shutdown and electrical isolation procedures
- Run full system diagnostic tests after installation
- Verify normal communication and complete equipment functions before resuming production operation
Important Reminder: Exact part number matching is mandatory for replacement. Boards with similar appearances cannot be regarded as equivalent substitutes, to prevent system incompatibility and production risks.
Spare Parts Supply
The 810-802902-038 Node 2 Motherboard is a specialized custom component for semiconductor equipment, serving as an indispensable replacement spare part for supporting Lam Research systems. It is available in used and surplus industrial spare part markets with stable inventory records.
We professionally supply full-series Lam Research semiconductor equipment spare parts, covering node boards, motherboards, PCBAs, control cards, interface boards, I/O assemblies and other dedicated electronic components for semiconductor production equipment.
For the 810-802902-038 model, customers can contact our team to confirm real-time inventory, product condition, testing reports, version revision, equipment compatibility, delivery cycle and quotation details before placing an order.
————————————————————————————————————-
If you would like to learn more about our products and services, please feel free to contact us at any time!
