1. Product Overview

2. Technical Parameters

3. Product Features

• High Measurement Accuracy: Delivers superior measuring precision to guarantee the accuracy of industrial process control
• Multi-channel Data Acquisition: Supports data collection and analysis via multiple independent channels
• Electrical Isolation Design: Electrical isolation is configured between every channel to optimize anti-interference performance
• Fast Switching Performance: Maximum switching time within 10ms, featuring rapid response speed
• Easy Installation: Adopts standard DIN rail mounting mode with M12 threaded terminal connection
• Complete Software Support: Matched with NI-DAQmx driver and LabVIEW programming environment
• High Operational Reliability: Adaptable to diversified complex industrial control scenarios

4. Structure & Composition

• Relay Contacts: The module is equipped with 8 switching contacts, which achieve electrical isolation from independent channels
• Power Supply System: Users can hybridly apply 24 V DC and 230 V AC relay outputs on a single module
• Built-in Protection Mechanism: The circuit composed of relay contacts is protected by a backup fuse with a maximum rated current of 6A (Characteristic: gG/gL)
• Standard Grounding Specification: Ground two paths of supply voltage to eliminate unsafe floating ground risks
• Standard Mounting Structure: DIN rail mounting design for neat arrangement inside switch cabinets
• Terminal Connection Structure: M12 threaded terminals are adopted for stable electrical wiring connection

5. Application Fields

• Industrial Automation: Collect on-site field signals and convert them into standard digital signals for processing and control by upper computers or PLC systems
• Industrial Process Control: Applied in process control systems for chemical, petroleum, electric power and other core industries
• Building Automation: Used for environmental monitoring and intelligent control of building facilities
• Electromechanical Equipment Monitoring: Suitable for application scenarios requiring high-speed and high-precision data acquisition, including signal processing, vibration analysis and other testing work
• General Industrial Control: Applied to motor control, valve adjustment, heater drive and other on-site control work
• Vertical Industry Deployment: Widely deployed in food processing, chemical engineering, petroleum, electric power, wastewater treatment and other industrial sectors
• Scientific Research & Engineering Test: Applicable to professional signal analysis, vibration detection, acoustic measurement and laboratory testing projects

6. Installation & Precautions

6.1 Installation Steps

• Mounting Mode: Install the module on standard DIN rails, and ensure standardized and safe layout inside the switch cabinet
• Grounding Treatment: Complete grounding operation for two paths of supply voltage to avoid unsafe floating ground faults
• Power Supply Standard: All 230V AC power supplies must be derived from the same phase of a unified power supply system
• Wiring Inspection: Implement firm and intact electrical connection via M12 threaded terminals before commissioning
