1. Product Overview

2. Main Parameters and Specifications

3. Product Features

• Modular Design: Adopts a compact modular structure, which greatly simplifies on-site installation, replacement and daily maintenance work, and improves the flexibility of system configuration.
• Automatic Electrical Connection: When mounted on the matching base plate, the module can automatically complete electrical connection with the CPU module without additional wiring operations, ensuring convenient and reliable connection.
• Configurable Protocols: Compatible with multiple mainstream industrial communication protocols. Users can flexibly configure the protocol type according to actual industrial application scenarios to meet diverse communication requirements.
• Hot-Swap Support: Supports hot-swap function when matched with the dedicated TU5xx-H series base, enabling module replacement and maintenance without system shutdown, improving equipment operation continuity.
• Anti-Interference Protection: The I/O channels are equipped with comprehensive protection mechanisms, including reverse connection protection, phase reversal protection, short-circuit protection and continuous overvoltage protection, which effectively enhances the stability and anti-interference ability of the module in complex industrial environments.
• Multi-Bus Compatibility: The AC500 system supports the parallel operation of multiple bus systems, covering mainstream industrial buses such as Ethernet, Profibus and Modbus, realizing seamless connection of multi-device and multi-network systems.

4. Structure and Composition

4.1 Hardware Structure

• Built-in central processing chip, specially used for efficient data processing and industrial communication task execution
• Equipped with standard interface connectors, including RJ45 Ethernet interface and serial communication interface options
• Integrated high-precision electronic components such as resistors and capacitors to ensure stable power supply and accurate signal transmission
• Adopts industrial-grade standard PCB design, with compact overall size and strong environmental adaptability

4.2 Installation Position

• Local Expansion: Can be installed on the right side of AC500 CPU modules or I/O modules for local system expansion
• Remote I/O Expansion: Can be mounted on the right side of mainstream communication modules including CI501-PNIO, CI502-PNIO, CI504-PNIO, CI506-PNIO, CI511-ETHCAT, CI512-ETHCAT, CI541-DP, CI542-DP, CI581-CN and CI582-CN to realize remote I/O data transmission and control functions

5. Application Fields

• Discrete control system: Automated control of production lines and industrial assembly equipment
• Process control system: Analog quantity real-time monitoring and automatic control of industrial production processes
• Timing control scenario: Industrial sequence timing control and logic scheduling
• Distributed I/O system: Remote data collection, signal transmission and equipment control
• Sequence control and transmission control of mechanical equipment
• SCADA (Supervisory Control And Data Acquisition) system data monitoring and control
• Network communication and data interaction requirements of industrial automation and embedded control systems

6. Installation and Maintenance

6.1 Installation Steps

1. Power Off Operation: Before any installation and disassembly operations on the AC500 system, cut off all power supplies including working power and external power supply to ensure operation safety.
2. Select Installation Position: Determine the installation position, and install the module on the right side of the compatible CPU module or designated expansion module.
3. Fix the Module: Adopt standard installation methods to fix the module firmly to avoid loose connection caused by equipment vibration.
4. Dock with Base Plate: Ensure the module is accurately docked with the industrial base plate, and the system will automatically complete electrical connection after correct docking.
5. Parameter Configuration: Complete communication protocol selection and parameter debugging through supporting programming software to match the system operation requirements.

6.2 Installation Precautions

• It is strictly forbidden to disassemble or remove the module in a live state to avoid equipment damage and safety accidents.
• Confirm that all power supplies are completely cut off before all maintenance and installation operations.
• The module must be installed and operated in a qualified temperature environment (-40°C to +70°C).
• Use matching base terminals such as TB511 and TB5620 to ensure the stability of electrical connection.

6.3 Maintenance Requirements

• Regularly check the connecting terminals and interfaces to eliminate hidden dangers of loose connection and poor contact.
• Keep the module surface and installation environment clean to prevent dust accumulation from affecting heat dissipation and signal transmission.
• Regularly observe and check the status of communication indicator lights to judge the normal operation of the module.
• Update the module firmware regularly to obtain the latest functional upgrades and security patches, ensuring stable and efficient system operation.
• Complete system configuration and program programming with Automation Builder 2.0 or above versions.
