ABB 5SHY3545L0010 3BHB013088R0001

5SHY3545L0010 is a modular component developed by ABB for high-voltage/medium-voltage power electronics and automation systems. It belongs to the IGCT (Integrated Gate-Commutated Thyristor) or IGBT power module series. Typically, it forms a complete power conversion or drive system with supporting components such as 3BHB013088R0001, 3BHE009681R0101, and GVC750BE101. This product is widely used in high-voltage power scenarios including wind power, photovoltaics, frequency converters, HVDC, and industrial drives.

1. Key Technical Specifications

2. Product Features

• High Reliability and Long Service Life: Low power loss, rigorous environmental testing, and a design life of up to 20 years.
• Modular Design: Supports plug-in installation for easy system expansion and maintenance.
• Wide Operating Temperature Range and Multiple Cooling Options: Optional air or water cooling to adapt to different power densities.
• High-Speed Switching: 20 kHz switching frequency improves system power density and reduces filter volume.
• Strong Compatibility: Can be used with ABB ACS series frequency converters, GVC drive boards, and other IGBT/IGCT modules.
• Easy Installation and Maintenance: Provides standardized racks, bolt or snap-on fixing methods, and supporting diagnostic software enables remote monitoring.

3. Structure and Composition

• Power semiconductor chip (IGBT/IGCT)
• Drive circuit (optical fiber input, short-circuit/overtemperature protection)
• Heat dissipation system (heat sink, fan, or water cooling pipeline)
• Housing and terminals (IEC standard-compliant metal housing with IP rating)

• 3BHB013088R0001 – Modular plug-in or bolt-fixed supporting component (often used as input/output interface)
• 3BHE009681R0101 – Drive board
• GVC750BE101 – Control/drive power board

4. Typical Application Areas

• Renewable Energy: Wind power converters, photovoltaic inverters
• High-Voltage Direct Current (HVDC) and Medium-Voltage Frequency Converters
• Industrial Drives: High-power motor drives for mining, petrochemical, steel, and water treatment industries
• Power Systems: Distribution networks, protection devices, intelligent auxiliary modules
• Other High-Voltage Power Electronics: Such as large pumps, compressors, and marine propulsion systems

5. Installation and Maintenance Guidelines

Pre-Installation Preparation

• Check on-site power supply, voltage level, and grounding conditions.
• Confirm the cooling method (air cooling or water cooling) and set up the heat dissipation channel.
• Reserve installation space according to rack specifications and ensure sufficient maintenance access.

Installation Steps

• Fix the module on a standard rack or bolt base.
• Connect the power supply, control signals (optical fiber or cable), and heat dissipation pipelines.
• Use anti-static gloves to avoid electrostatic discharge damage to semiconductors.

Commissioning and Testing

• Use the diagnostic software provided by ABB for parameter setting and fault self-test.
• Verify that protection functions such as short-circuit, overtemperature, and undervoltage work normally.

Daily Maintenance

• Regularly clean dust on the heat sink surface and check the operation status of fans or water pumps.
• Monitor module temperature and power loss, and perform preventive maintenance based on monitoring data.
• In case of abnormal alarms, refer to diagnostic logs for quick troubleshooting.

Safety Precautions

• Ensure power is cut off and grounded before operation, and comply with safety standards such as IEC 61800‑5‑1/IEC 61508.
• Wear insulating gloves during maintenance to avoid direct contact with high-voltage terminals.

————————————————————————————————————-
