ABB AO845A-eA

1. Overview

2. Key Specifications

• Number of Channels: 8 independent analog outputs
• Output Types: Selectable voltage (-10 V–+10 V) and current (4–20 mA, 0–20 mA)
• Resolution: 16-bit (high precision)
• Output Accuracy: 0.1% (typical)
• Supply Voltage: 24 V DC
• Operating Temperature: -40 °C to +70 °C
• Dimensions: Approximately 90 mm × 14 mm × 115 mm (width × height × depth)
• Mounting Method: DIN rail mounting, supporting stacked installation
• Certifications: CE, ATEX, FM, CSA, IECEx, etc.

3. Product Features

• High Resolution and Precision: 16-bit resolution and 0.1% accuracy ensure the delicacy of output signals.
• Multiple Output Ranges: Configurable -10 V–+10 V, 4–20 mA, 0–20 mA, etc., to meet diverse field requirements.
• Channel Isolation: Each output channel is equipped with electrical isolation to suppress interference and enhance system reliability.
• Fast Update Rate: High-speed sampling (around 100 µs) and rapid signal updates make it suitable for dynamic process control.
• Diagnostic Functions: Built-in advanced diagnostics enable remote monitoring of channel status, short-circuit protection, and more.
• Modular Design: Can be flexibly combined with other ABB I/O modules, supporting redundant or centralized layouts.

4. Structure and Components

• Housing: Metal protective casing with IP20 protection rating.
• Connectors: Used for wiring with field devices and upper-level systems.
• Circuit Board: Includes signal processing, analog-to-digital/digital-to-analog conversion (ADC/DAC), and isolation circuits.
• Terminal Block: Each output channel is equipped with an independent terminal for convenient on-site wiring.

5. Application Fields

• Process Control: Analog control of valves, pumps, and speed governors.
• Automation Systems: Speed/position adjustment of production lines and packaging equipment.
• Energy Management: Current/voltage output for generator sets and frequency converters.
• Instrument Calibration: Signal source for laboratory or on-site instruments.
• Redundant Systems: Dual-channel or multi-module redundant configurations to improve reliability.

6. Installation and Maintenance

• Installation: Fixed via DIN rail; it is recommended to use standard screws and rail accessories. Modules can be stacked for efficient space utilization.
• Wiring: Select the corresponding voltage/current terminals according to the output range, ensuring wiring complies with IEC standards.
• Commissioning: Channel parameter setting and calibration can be performed through ABB’s dedicated configuration software (e.g., System 800xA Engineering).
• Maintenance: The module has a self-diagnostic function; faults can be located via system alarms when they occur. Regularly check the tightness of wiring and heat dissipation conditions to ensure the operating temperature stays within the specified range.
