ABB CP6607 1SAP560710R0001

1. Product Overview

2. Technical Parameters

3. Product Features

• High-performance HMI: Adaptable to challenging application environments and fully compatible with the ABB CP600 control panel platform.
• Robust and Durable: Constructed with an aluminum alloy housing and genuine glass screen for enhanced durability.
• High Protection Grade: Equipped with a rugged aluminum front frame and features IP66 protection rating.
• Wide Temperature Adaptability: Enables stable and reliable operation in a wide ambient temperature range from -20°C to +60°C.
• Sleek Appearance: Adopts an all-black front design, matching the design requirements of various machines and systems.
• Standard Compliance: Complies with the 2014/30/EU EMC Directive and a series of international industry standards.
• Multi-functional Operation: Supports multi-touch operation for flexible and intuitive control.
• High Flexibility: Provides machine manufacturers and system integrators with diversified product options covering different functions and price ranges.

4. Structure and Composition

• Housing Structure: Heavy-duty aluminum alloy housing with excellent structural stability and corrosion resistance.
• Screen Assembly: Adopts genuine glass screen and TFT LCD display technology, delivering clear display effects and long service life.
• Front Panel Design: All-black front foil design, supporting both horizontal and vertical installation and use.
• Interface Configuration: Comes with comprehensive interfaces, including two 10/100 Mb Ethernet ports, RS-232/RS-485/RS-422 serial ports, a USB v2.0 port, and an SD card slot.
• Internal Components: Built-in rechargeable lithium-ion battery for hardware real-time clock power supply, 4GB flash memory and 1GB RAM to ensure efficient operating performance.
• Installation Structure: Equipped with dedicated fixing brackets to support wall-mounted installation for flexible layout.

5. Application Fields

• PB610 Application Visualization: Specialized for display and operation control of ABB PB610 applications.
• AC500 V3 Web Server: Applied to web server visualization of ABB AC500 V3 series PLCs.
• For Machine Manufacturers: Provides professional and reliable HMI solutions for various mechanical equipment.
• For System Integrators: Meets diversified visualization and control demands in system integration projects.
• Harsh Industrial Environments: Suitable for industrial application scenarios with complex and harsh operating conditions.
• Diversified Industries: Widely applicable to automatic control fields including electric power, chemical engineering, manufacturing and other industrial sectors.
