ABB 07KT98 H3

Main Technical Parameters

Interface Configuration

• 2 × Ethernet Interfaces
• 1 × RS-232/-422/-485 Serial Interface
• 2 × USB 2.0 Interfaces
• 1 × SD Card Slot
• 2 × Expansion Slots

Other Parameters

• Memory Capacity: 256MB
• Password Protection Level: 8 Levels

Product Features

• High-Definition Display: Equipped with a 15-inch TFT color touch screen, 64K color display and 1024×768 pixel resolution, delivering clear and intuitive operation interface presentation.
• Powerful Communication Capability: Built with multiple network interfaces, supporting Ethernet, serial communication and USB connection, facilitating seamless interconnection and data interaction with various industrial devices.
• PB610 Integration: Pre-installed with PB610 runtime license, enabling perfect compatibility with ABB Panel Builder software and simplifying the development process of HMI projects.
• Advanced Security Protection: Features 8-level password protection to effectively ensure operational safety and data confidentiality for industrial control systems.
• Excellent Environmental Adaptability: The front panel adopts IP66 ingress protection rating, which can adapt to harsh and complex industrial field environments.
• Strong Expandability: Designed with 2 expansion slots to support modular functional expansion and flexible configuration upgrades.
• Reliable Warranty Service: Comes with a 12-month warranty and supports global delivery services.

Structure and Composition

• Display Module: 15-inch TFT LCD screen with capacitive or resistive touch technology for sensitive and accurate operation.
• Main Control Board: Built-in processor and 256MB memory, responsible for core data processing and communication management.
• Interface Module: Integrated with Ethernet, RS-232/485, USB and other mainstream industrial communication interfaces.
• Storage Module: Equipped with an SD card slot for convenient data storage and program loading.
• Expansion Interface: Two expansion slots reserved for connecting additional functional modules to expand device performance.
• Protective Housing: The front panel with IP66 protection rating meets strict industrial environmental protection standards.

Application Fields

• Distributed Control System (DCS): Used for centralized monitoring and decentralized control of large-scale factory production processes.
• PLC System: Cooperates with programmable logic controllers to realize human-computer interaction and real-time process monitoring.
• Robot Control System: Serves as the operation interface for industrial robots, supporting program editing, parameter adjustment and status monitoring.
• Large Servo System: Applied for parameter setting, operation control and status monitoring of servo drives.
• Industrial Automation Production Line: Suitable for monitoring, management and operation control of various automated production lines.
• PB610 Panel Builder Application: Specially designed for the development and runtime operation of ABB Panel Builder software projects.
