ABB CP800

The ABB CP800 is a high-performance communication processor module designed for industrial automation. It is compatible with the ABB Symphony Plus (HPC800) system, delivering robust data processing and multi-protocol communication capabilities. Ideal for distributed control systems (DCS) and motion control applications.

Key Specifications

• Power Supply: 24 V DC ±10 % (powered via system bus)
• Power Consumption: Approx. 10 W (typical value)
• Processor: 2 × ColdFire 32‑bit, 256 MHz (shared with HPC800)
• Memory: 64 MB RAM, 4 MB ROM
• Operating Temperature: 0 °C to 70 °C; Storage Temperature: -20 °C to 70 °C
• Dimensions & Weight: Approx. 170 mm × 104 mm × 74 mm; Weight: approx. 0.99 kg
• Interfaces: 1 × Plant Network (PN800), 10/100 Mbps Ethernet, 1 × serial port; supports industrial networks including Profibus, Modbus, and PROFINET
• Mounting Method: DIN rail mounting

Product Features

1. Modular DesignCombines with the HPC800 to form a complete automation control system, facilitating easy expansion and maintenance.
2. Multi-Protocol CompatibilityIntegrates a wide range of industrial communication protocols, supporting both fieldbus and Ethernet. Enables seamless integration with PLCs, sensors, actuators, and other devices.
3. High ReliabilityIndustrial-grade hardware with anti-interference and high-temperature resistance, suitable for harsh field environments.
4. Low Power ConsumptionTypical power consumption of only 10 W, reducing energy costs.
5. Flexible ConfigurationSupports multiple programming languages and development environments, allowing customized functionality based on specific requirements.

Structure and Components

• CPU/Processor Unit: Dual ColdFire processors for real-time data processing.
• Storage Unit: Shared RAM and ROM for storing programs and operational data.
• Communication Interface Board: Includes Plant Network, Ethernet, serial port, and other interfaces.
• Power Supply Module: 24 V DC power supply with voltage regulation and protection functions.
• Chassis and Heat Dissipation Structure: Metal housing paired with heat sinks to maintain stable operation within the specified temperature range.

Typical Application Fields

• Robot and collaborative robot control
• Automated production lines and packaging machinery
• CNC machine tools and precision machining
• Process control in power, petrochemical, metallurgical industries, etc.
• Any industrial system requiring high-precision motion control and reliable data communication

Installation and Maintenance Guidelines

Installation

• Mount the module on a DIN rail to ensure stability and facilitate future replacement.
• Connect power and communication cables, then power on the system for self-testing.

Wiring

• Follow the wiring diagrams recommended by ABB, especially the cabling specifications for Plant Network and Ethernet ports.

Software Configuration

• Use ABB’s engineering tools (e.g., Automation Builder) for parameter setting, firmware upgrading, and function debugging.

Routine Inspection

• Regularly check for dust accumulation on heat sinks, loose interface connections, and whether the power supply voltage is within the rated range.

Troubleshooting

• Leverage built-in diagnostic logs and alarm functions to quickly locate communication abnormalities or hardware faults.
