ABB ETER1 R1G 37540025 Ethernet interface module
ABB ETER1 R1G 37540025
1. Product Overview
2. Main Technical Parameters
|
Parameter Item
|
Technical Specifications
|
|---|---|
|
Model
|
ETER1-FU / 37540025
|
|
Ethernet Ports
|
4 × 10/100BaseT
|
|
Serial Ports
|
8 × 2Mbit/s
|
|
Bus Access
|
MLPPP (Multi-Link PPP) access for PBus bus
|
|
Operating Voltage
|
24V DC (Industrial Standard)
|
|
Operating Temperature
|
-10°C to +55°C (Inferred from specifications of similar ABB modules)
|
|
Ingress Protection Rating
|
IP40 (Compliant with ABB similar product standards)
|
|
Installation Method
|
35mm DIN rail mounting or rack mounting
|
|
Weight
|
Approx. 220g (Estimated based on similar ABB modules)
|
3. Product Features
3.1 High Reliability Design
- Adopts industrial-grade components, suitable for harsh industrial environments
- Possesses excellent EMC (Electromagnetic Compatibility) anti-interference performance
3.2 Flexible Network Architecture
- Supports flexible configuration of 4 × 10/100M Ethernet ports
- 8 × 2Mbit/s interfaces provide sufficient expansion capability
- Supports MLPPP protocol for link aggregation and redundancy
3.3 Integrated Design
- Modular structure facilitates system expansion and maintenance
- Seamlessly integrated with ABB control systems
3.4 Strong Environmental Adaptability
- Made of materials with excellent temperature adaptability
- Applicable to outdoor high-temperature and low-temperature environments
3.5 Intelligent Management
- Supports remote configuration and real-time status monitoring
- Enables fault diagnosis and data feedback functions
4. Structure and Composition
|
Component
|
Function Description
|
|---|---|
|
Ethernet Interface
|
4×10/100BaseT RJ45 ports with auto-negotiation function
|
|
Serial Port Module
|
8 × 2Mbit/s serial communication interfaces for extended data transmission
|
|
Bus Interface
|
PBus bus interface for communication with the main control system
|
|
Control Processor
|
Embedded microprocessor responsible for data routing and data processing
|
|
Power Supply Module
|
24V DC power supply, supports redundant power input
|
|
Status Indicator
|
LED indicators display the status of power supply, network, bus and other working states
|
|
Interface Connector
|
Used for external wiring and module fixing
|
|
Mounting Rail & Buckle
|
Standard industrial mounting structure for fast and stable installation
|
5. Application Fields
5.1 Industrial Automation Systems
- Control of factory automated production lines
- Control systems for discrete manufacturing and process industries
5.2 Building Automation
- Communication network integration for intelligent buildings
- Network access for security monitoring systems
5.3 Energy and Power Industry
- Control networks for renewable energy systems such as wind power generation
- Communication interfaces for substation automation systems
5.4 Transportation Industry
- Signal and control systems for rail transit
- Network access for intelligent transportation systems
————————————————————————————————————-
