ABB FS450R12KE3/AGDR-71C driver combination

Short Description:

The ABB FS450R12KE3/AGDR-71C is a high-performance IGBT module and drive combination, widely used in ABB’s frequency converters. This integrated module and drive work together to control the power output of ABB inverters, ensuring efficient and reliable performance. Featuring advanced silicon technology and innovative packaging, it delivers high efficiency, high frequency, and high voltage capabilities, making it suitable for various industrial automation and power electronics applications.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: ABB

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

ABB FS450R12KE3/AGDR-71C

1. Overview

2. Key Parameters

Rated Voltage: 1200V
Rated Current: 450A
Operating Voltage: 24V DC
Input Current: 250mA
Output Current: Up to 1A
Operating Temperature Range: -40°C to +70°C
Net Weight: 0.5 kg
Package Type: ECONO+
Configuration: Six-unit IGBT module
Technical Features: High switching speed, high efficiency, and high reliability

3. Product Features

High Performance: The module and drive combination offers fast switching speeds and high efficiency, meeting the demands of advanced frequency converters.
High Reliability: Designed for harsh industrial environments, ensuring long-term stable operation under demanding conditions.
Modular Design: Easy installation and maintenance due to its modular construction.
Strong Compatibility: Compatible with ABB’s ACS series frequency converters, suitable for diverse industrial automation systems.
Multi-Power Support: Supports three-phase power supplies and motor power adaptability.
Smart Series: Enables intelligent control for complex industrial automation scenarios.

4. Structure and Components

The ABB FS450R12KE3/AGDR-71C consists of two main components:

IGBT Module (FS450R12KE3)

The core component responsible for converting DC to AC and regulating motor speed.
Rated voltage: 1200V; rated current: 450A.
Features a six-unit IGBT module design for enhanced power handling.

Drive Unit (AGDR-71C)

Controls the IGBT module, ensuring precise switching under varying loads.
Works in synergy with the IGBT module for stable operation across different industrial applications.
Supports multiple control signal inputs for flexibility in automation systems.

5. Applications

The ABB FS450R12KE3/AGDR-71C is widely used in:

Frequency Converters: Primarily in ABB’s ACS series for motor speed and torque control.
Industrial Automation: High-power switching applications such as motor drives, elevator controls, and crane systems.
Power Electronics: Including UPS (uninterruptible power supplies), inverters, and frequency converters.
Large Servo Systems: Provides precise motor control in high-performance servo applications.
Oil & Gas, Power, Metallurgy, and Water Treatment: Used for level measurement, industrial equipment control, and more.

———————————————————————————————————————————
