ABB KBA 07KT94I GJR5252100R3161 Basic Unit

Short Description:

The ABB KBA 07KT94I GJR5252100R3161 is a Basic Unit of the ABB Advant Controller 31 series and a part of the ABB Advant OCS product line.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: ABB

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

ABB KBA 07KT94I GJR5252100R3161

1. Product Overview

The ABB KBA 07KT94I GJR5252100R3161 is a Basic Unit of the ABB Advant Controller 31 series and a part of the ABB Advant OCS product line. It is a compact and multi-functional PLC (Programmable Logic Controller) designed for small and medium-sized industrial automation applications.

2. Main Parameters

Parameter Item	Specification
Manufacturer	ABB
Product Series	Advant Controller 31 (AC31)
Product Type	Basic Unit
Order Number	GJR5252100R3161
Origin	Germany / Spain / USA, etc.
Dimensions	Approx. 16cm × 16cm × 12cm
Weight	Approx. 0.8kg
Power Supply Voltage	24V DC
Power Consumption	5W / 10W
Digital Input	8 isolated 24V DC inputs
Digital Output	6 relay outputs or transistor outputs
CPU Capacity	Supports a maximum of 15 Series 100 I/O modules

3. Product Features

Modular Design: Adopts an expandable module architecture that enables flexible configuration of I/O points to meet diverse application requirements.

Powerful Communication Capability: Equipped with an RS-232 communication interface, it supports programming and data communication via ASCII or Modbus protocols. The default communication parameters are set to a baud rate of 9600, 8 data bits, 1 stop bit, and no parity, which can be adjusted through software configuration.

International Standard Compliance: The device complies with IEC 1131 Part 2 standard and Overvoltage Category II, meeting the requirements of DIN VDE 0110 Part 2. It features excellent ESD (Electrostatic Discharge) resistance in line with EN 61000-4-2 standard, with an air discharge voltage of 8kV and a contact discharge voltage of 4kV.

Comprehensive Status Indication: The controller is fitted with multiple LED indicators including RUN, FK1-FK3 (Fault), Sup (Power Supply), and Batt (Battery), facilitating real-time operation monitoring and rapid fault diagnosis.

High Software Compatibility: PLC ladder logic programs can be developed using sequential control design methods, which are easier to learn and master compared with traditional relay control systems, significantly shortening program design cycles.

4. Structure and Composition

In accordance with the official ABB technical manual, the structural design of this basic unit is divided into multiple functional areas as follows:

Left Area: Consists of DC power input terminals (DC-IN 15W, 24V) and multiple I/O ports (X1 to X5), used for connecting digital input and output signal lines.

Central Area: Serves as the main identification area, printed with the mark “ABB Advant Controller 31 Basic Unit”, and clearly labeled with address numbers and functional descriptions of all ports.

Right Area: The operation and control area, equipped with a RUN/STOP button, two serial communication ports (COM1/COM2), and a CS31 bus interface for connecting expansion modules.

Top and Bottom: Uniformly arranged with green LED status indicators to display the real-time operating status of the controller.

5. Application Fields

Printing Industry: Dedicated control system for KBA printing presses.

General Industrial Automation: Applicable to control and monitoring scenarios of various industrial production processes.

Advant OCS 800XA Product Line: Acts as a cost-effective solution for small and medium-sized automation applications in the product line.

Factory Automation: Widely used in ABB Factory Automation business scenarios, covering production control, process monitoring and other core tasks.

Small and Medium-Sized Control Systems: An ideal replacement for traditional relay control systems, effectively reducing the workload of control cabinet design, on-site installation and wiring.

6. Installation and Maintenance

6.1 Installation Requirements

Installation Method: Support DIN rail mounting. The thickness of the rail shall be included in the installation depth calculation when adopting rail installation.

Environmental Requirements: The device meets Pollution Degree 2 standards. Ambient temperature and humidity conditions must be fully considered during installation to ensure stable operation.

Wiring Specifications: Adopt AWG 14 Cu Str 60°C cables for wiring, with a standard wiring torque of 4.5 Lbs-inch (0.5Nm).

6.2 Maintenance Guidelines

Warranty Policy: The original manufacturer provides a 12-month factory warranty service. Authorized professional suppliers can provide an extended 2-year warranty service.

Repair Service: Faulty devices can be returned and tested through official professional service providers to ensure performance recovery.

Commissioning Method: PLC programs can be simulated and debugged in the laboratory by simulating input signals with micro switches and observing output status via LED indicators. On-site operation faults and abnormal conditions are mostly solved by program modification and optimization.
