ABB NINT-71C Digital Input (DI) Module
ABB NINT-71C
NINT‑71C is a standard Digital Input (DI) module provided by ABB for its 1756‑B series PLCs (such as AC500 and S7‑1500). Featuring a modular design, it can be directly inserted into the PLC’s I/O slot to enable rapid acquisition of on-site discrete signals.
Key Technical Specifications
- Input Type: 24 V DC DC digital input (12 V DC optional)
- Number of Channels: 16 channels (each with independent isolation)
- Rated Current: ≤ 20 mA per channel (total power consumption ≤ 320 mA)
- Response Time: ≤ 1 ms (compliant with IEC 60730 standard)
- Operating Temperature: -25 °C to +70 °C (industrial-grade extension to +85 °C optional)
- Protection Class: IP20 (IP65 protective housing optional)
- Communication Interface: Direct data reading via PLC bus (PROFIBUS, PROFINET, Ethernet/IP, etc.)
Product Features
- High Reliability: Equipped with industrial-grade components, it has strong anti-interference capability and is suitable for harsh on-site environments.
- High Precision: 16-bit sampling resolution ensures accurate capture of discrete signals.
- Flexibility: Supports multiple input voltages and optional protective housings to meet diverse on-site requirements.
- Modular Maintenance: Hot-swappable design allows for quick module replacement in case of faults, minimizing downtime.
- Excellent Compatibility: Compatible with multiple generations of ABB PLC platforms and features a unified programming interface, facilitating system upgrades.
Structure and Composition
- Module Body: Includes 16 digital input terminals, power supply terminals, status indicator lights, and a module number label.
- Terminal Block: Each channel is equipped with screw-type terminals, supporting both screw crimping and spring clip connection methods.
- Internal Circuitry: Each input channel is fitted with optocoupler isolation, filter capacitors, and anti-noise circuits to ensure signal integrity.
- Housing: Standard plastic housing (IP20); optional metal protective housing (IP65) for dustproof and waterproof applications.
Typical Application Fields
- Automated Production Lines: Acquisition of discrete signals from sensors, limit switches, buttons, etc.
- Process Control: Monitoring of valve statuses, pump start/stop signals, and emergency stop switches.
- Building and Facility Management: Digital input for access control, fire alarm, and environmental monitoring systems.
- Energy and Power: Input of relay protection signals in power distribution cabinets and substations.
- Transportation and Logistics: On-site control of conveyor belts, automatic doors, loading detection, and other equipment.
Installation and Maintenance Guidelines
Installation
- Turn off the PLC power supply, insert the NINT‑71C into the corresponding I/O slot, and ensure the latch is securely locked.
- Connect the 24 V DC power supply and signal lines to the module’s power terminals and respective input terminals according to the wiring diagram.
- If a protective housing is used, complete the sealing treatment on-site to ensure the required protection class.
Commissioning
- Add the module model in the PLC programming software (e.g., ABB Automation Builder), and the corresponding I/O addresses will be generated automatically.
- Check the status of each input channel through the online monitoring function to confirm normal signal acquisition.
Maintenance
- Regularly inspect terminal connections to prevent loosening or corrosion.
- For high-frequency switching inputs, appropriately install debounce capacitors or filter circuits.
- In case of faults, use the hot-swappable feature to replace the module quickly, and then re-map the address in the software.
————————————————————————————————————-
