ABB PP846 3BSE042238R1 Operator Panel
ABB PP846 3BSE042238R1
1. Product Overview
2. Technical Specifications
|
Parameter Item
|
Specification Value
|
|---|---|
|
Model
|
PP846 3BSE042238R1
|
|
Brand
|
ABB
|
|
Series
|
Panel 800
|
|
Display Size
|
10.4 Inches
|
|
Display Type
|
Color TFT LCD
|
|
Resolution
|
640 × 480 Pixels / 800 × 600 Pixels
|
|
Display Color
|
256 Colors
|
|
Display Brightness
|
200 cd/m²
|
|
Display Contrast
|
200:1
|
|
Touch Screen Type
|
Resistive, Hardness 3H
|
|
Function Keys
|
24 Pcs
|
|
Indicator Lights
|
8 Pcs
|
|
Processor
|
266 MHz ARM9
|
|
Memory
|
32MB RAM + 32MB Flash
|
|
Power Input
|
24V DC
|
|
Power Consumption
|
18W
|
|
Communication Interfaces
|
RS-232, RS-485, Ethernet
|
|
Supported Protocols
|
Modbus RTU/TCP, ABB CS31, Advant, Master, etc.
|
|
Environmental Parameters
|
|
|
Operating Temperature
|
-20°C – +60°C
|
|
Storage Temperature
|
-40°C – +85°C
|
|
Relative Humidity
|
5% – 95% RH (Non-condensing)
|
|
Dimensions
|
290mm × 226mm × 59mm
|
|
Weight
|
1.6kg – 3.28kg
|
3. Product Features
3.1 Reliability and Stability
- Adopts industrial-grade design, suitable for harsh industrial environments
- High reliability and stability to ensure long-term continuous operation
3.2 Modular Design
- Modular structure, easy to install and maintain
- Supports flexible configuration, which can be adjusted according to application requirements
3.3 Electrical Safety Features
- Electrical isolation between input channels and the control system to improve safety
- Equipped with filtering function to effectively suppress electromagnetic interference
3.4 Operational Convenience
- User-friendly interface, simple and intuitive operation
- Integrated function keys for quick operation
4. Structure and Composition
|
Component
|
Description
|
|---|---|
|
Display Screen
|
10.4-inch color TFT LCD, providing clear graphics and text display
|
|
Touch Module
|
Resistive touch screen, supporting precise touch operation
|
|
Function Key Area
|
24 programmable function keys
|
|
Status Indicator Lights
|
8 indicator lights, displaying the system working status
|
|
Communication Interface Module
|
Integrated RS-232, RS-485 and Ethernet interfaces
|
|
Processing Unit
|
ARM9 processor, responsible for data processing and communication
|
|
Memory Module
|
32MB RAM + 32MB Flash, storing programs and data
|
|
Power Module
|
24VDC input power supply, with internal voltage stabilization conversion
|
5. Application Fields
- Industrial Automation Control Systems: Process monitoring and control
- 800xA Automation System: As the core component of human-machine interaction
- Compact Product Suite Applications: Various industrial control scenarios
- Production Line Automation: Process control in manufacturing and processing industries
- Power and Energy Systems: Power distribution and energy management
- Smart Manufacturing: Digital production line monitoring
- Mechanical Equipment Control: Integration of various industrial equipment
————————————————————————————————————-
