ABB PXAH401

1. Overview

The ABB PXAH401 is an industrial automation product manufactured by ABB, designed primarily for displaying and controlling various parameters in industrial processes. As part of a Human-Machine Interface (HMI), it provides operators with a means to interact with automation systems. This product features a high-resolution graphic display, multiple communication interfaces, programmable keys, and is suitable for harsh industrial environments.

2. Specifications

• Display size: 5.7-inch or 7-inch (varies by model)
• Display resolution: 320 x 240 pixels or 800 x 480 pixels
• Number of keys: 6 programmable keys
• Communication interfaces: RS-232, RS-485, Ethernet, USB, etc.
• Operating temperature: -20°C to +60°C or -40°C to +85°C
• Storage temperature: -40°C to +80°C or -20°C to +70°C
• Humidity: 5% to 95% (non-condensing)
• Protection rating: IP65
• Dimensions: 146 mm x 85 mm x 25 mm or 150 mm x 100 mm x 45 mm
• Weight: 0.5 kg or 1.3 kg
• Power supply: 24V DC

3. Key Features

• High-resolution graphic display: Ensures clear visibility of process data.
• Programmable keys: Allows user-defined functions for enhanced flexibility.
• Multiple communication interfaces: Supports Ethernet, RS-232, RS-485, USB, etc., enabling seamless device integration.
• Rugged design: Resistant to interference and stable in harsh industrial conditions.
• Easy installation & maintenance: Modular design simplifies setup and servicing.
• Compliance: Meets IEC standards and certifications (UL, CE).
• High reliability: Uses premium components and advanced circuitry for stable operation.
• Multilingual support: Accommodates global users.
• Expandability: Supports additional functional modules for diverse applications.

4. Structure & Components

The ABB PXAH401 consists of:

• Display: High-resolution color touchscreen for process data, alarms, and trends.
• Keys: 6 programmable control buttons.
• Communication ports: Ethernet, RS-232, RS-485, USB, etc.
• Power input: 24V DC supply.
• Control unit: Includes CPU and memory for logic/data processing.
• Enclosure: Metal/plastic housing with robust protection.

5. Applications

The ABB PXAH401 is widely used in:

• Oil & Gas: Refineries, natural gas processing.
• Chemical: Reaction control, pH regulation.
• Power: Power plants, substation monitoring.
• Water Treatment: Chlorine/turbidity monitoring.
• Manufacturing: Automated production lines (e.g., automotive, machinery).
• Building Automation: HVAC, lighting control.
• Metallurgy: Process control.
• Food & Beverage: Equipment monitoring.
• Pulp & Paper: Paper machine control.

6. Installation & Maintenance

• Installation: Typically panel-mounted; requires proper power supply and interface connections. Network setup may be needed for large systems.
• Maintenance: Regular checks, cleaning, firmware updates, and interface inspections. Remote diagnostics are recommended for complex systems.
• Troubleshooting: Consult the manual or contact ABB technical support for issues.

———————————————————————————————————————————
