ABB SD822 Power/Actuator Module
ABB SD822
Overview
ABB SD822 is a high-reliability power supply/actuator module designed for industrial automation, compatible with ABB systems and third-party control systems.
It supports multiple voltage inputs, delivers a stable 24 V DC output, and is featured with modular design and self-diagnostic functionality.
Specifications
- Rated Voltage: 115/230 VAC (switchable)
- Output Voltage: 24 V DC, 5 A, power rating approx. 120 W
- Operating Temperature: -40 °C to +70 °C
- Protection Class: IP20 (module) / IP65 (high-voltage circuit breaker version)
- Dimensions/Weight: approx. 114 mm × 45 mm × 120 mm, weight 0.2 kg (module) or 800 kg (high-voltage circuit breaker)
Product Features
- Modular Design: Facilitates quick installation and hot-swappable replacement, minimizing downtime.
- Comprehensive Diagnostic Functions: Monitors power supply status in real time and provides fault self-diagnosis.
- High Reliability: Equipped with industrial-grade components and strong anti-interference capability, suitable for harsh environments.
- Flexible Configuration: Supports multiple communication protocols (Profibus-DP, fieldbus, etc.).
- Versatile Mounting Options: DIN rail, C-rail or wall-mounted installation, meeting diverse on-site requirements.
Structure and Components
- Power Supply Module Main Body: Includes rectification, voltage stabilization and filtering circuits.
- Front Panel Connector: Supports C-rail, wall-mounted or DIN rail installation.
- Internal Diagnostic Chip: Enables self-test and status indication.
- Heat Dissipation Device: Ensures reliable operation under high-temperature conditions.
Application Fields
- Process Control: Continuous production systems in chemical, petroleum, oil refining industries, etc.
- Power Systems: High-voltage circuit breaker versions for power plants and substations.
- Industrial Automation: PLC, DCS, robots, smart manufacturing equipment.
- Infrastructure: Critical power supporting facilities for railways, subways, airports, etc.
Installation and Maintenance
- Installation: Can be directly mounted on standard cabinets or DIN rails with bolt fixing points provided; the high-voltage circuit breaker adopts electric operation and has IP65 protection.
- Maintenance: Modular structure supports hot swapping, and diagnostic functions help quickly locate faults, reducing on-site downtime.
- Environmental Requirements: Comply with operating temperature and protection class specifications to ensure reliable operation in the environment of -40 °C to +70 °C.
————————————————————————————————————-
