ABB WMDOLT2-A75(65KA)6E 1TGE106812P0001 Low Voltage Distribution Panel
ABB WMDOLT2-A75(65KA)6E 1TGE106812P0001
The ABB WMDOLT2-A75 is a low-voltage distribution board (switchgear cabinet) belonging to the ABB WMDOLT series, engineered specifically for industrial power distribution, control, and protection applications. Boasting a rated short-circuit breaking capacity of 65 kA, this model complies with the requirements for high-breaking-capacity distribution equipment specified in IEC 60947-2, making it ideal for scenarios demanding superior reliability and safety.
Key Technical Specifications
- Rated Voltage: 400 V (Three-phase)
- Rated Current: Configurable with standard ratings including 400 A, 630 A, 800 A, etc., based on specific requirements
- Short-Circuit Breaking Capacity: 65 kA (at 240 V AC)
- Pole Number: 3P (including N and PE)
- Circuit Breaker Type: Molded Case Switch, fixed mounting
- Structural Form: Frame type (Frame Rating = 400) with lock/tag bracket for safe locking and maintenance
- Additional Features: Optional lock/tag bracket and position indicator light; no shunt-trip device included
- Protection Class: IP20 (for indoor dry environments)
Product Features
- High Breaking Capacity: The 65 kA short-circuit breaking capacity represents a high level in low-voltage distribution systems, enabling reliable interruption of fault currents in the event of sudden short circuits.
- Modular Design: Adopts a standardized frame structure, facilitating on-site rapid assembly, capacity expansion, and component replacement.
- Robust Mechanical Structure: Fixed molded case circuit breaker with excellent vibration and impact resistance, suitable for harsh industrial field environments.
- Safety Locking Function: Equipped with a dedicated lock/tag bracket to meet safety locking requirements during on-site maintenance.
- Strong Compatibility: Seamlessly integrates with other ABB low-voltage products (such as contactors, relays, and PLCs) to form a complete power distribution and control system.
Structure and Components
- Frame Body: Steel frame providing mechanical support and installation reference.
- Circuit Breaker Module: Molded case switch integrated with contacts, spring mechanisms, and breaking mechanisms.
- Terminal Blocks: Front-mounted or rear-mounted terminal blocks for convenient on-site wiring.
- Lock/Tag Bracket: Used for safety locking during maintenance.
- Indicator Light Base (Optional): Displays the circuit breaker status (closed or open).
Typical Application Fields
- Main and distribution switchgear cabinets for industrial production lines
- Power distribution systems in high-load industries such as power generation, petrochemicals, metallurgy, and papermaking
- Power supply protection for large machine tools and automated production lines
- Power distribution networks requiring high breaking capacity (e.g., front-end of frequency converters and servo systems)
Installation and Maintenance Guidelines
- On-Site Inspection: Before installation, verify that the frame dimensions, circuit breaker model, and rated current match the design requirements.
- Wiring Method: Front-mounted wiring is recommended for ease of future maintenance; ensure bolt fastening and intact insulation during wiring.
- Lock/Tag Operation: Prior to maintenance, use the matching lock/tag bracket to place the circuit breaker in the open position and lock it to prevent misoperation.
- Regular Inspection: Check contact wear, spring tension, and indicator light function every 6 months; perform cleaning or replacement when necessary.
- Temperature Monitoring: Monitor cabinet temperature during high-load operation to ensure unobstructed heat dissipation channels and prevent contact welding caused by overheating.
————————————————————————————————————-
