Schneider AEG 557VIC12620

The Schneider AEG 557VIC12620 is a modular current transformer (CT) engineered for medium and low-voltage distribution systems. Boasting a compact design, it delivers high-precision current measurement and protection capabilities, and is widely integrated into switchgear cabinets, substations, and industrial automation systems.

Key Specifications

• Secondary Rated Current: 5 A
• Primary Rated Current Range: 0.5 A – 2500 A (optional)
• Secondary Rated Voltage: 5 V (50 Hz)
• Accuracy Class: 0.5 % (Class 0.5)
• Frequency Range: 45 Hz – 65 Hz
• Insulation Class: Class B (withstand voltage: 5 kV)
• Operating Temperature: -15 ℃ – +40 ℃ (average temperature ≤ 35 ℃)

Product Features

1. Five Protection Functions


   Short-circuit protection, overload protection, misoperation prevention, moisture resistance, and dust resistance ensure maximum operational safety.

2. Compact Structure


   Small footprint enables easy installation in space-constrained environments.

3. Extended Service Life


   Core components (contactors) support up to 2.5 million electrical operations and allow high-frequency cycling (600 operations/hour).

4. High-Voltage Current-Limiting Fuses


   Rapidly interrupt short-circuit currents to minimize impact on system and equipment integrity.

5. Flexible Modular Integration


   Directly compatible with Schneider AEG VCB cabinets, offering multiple wiring configurations: top-in top-out, bottom-in bottom-out, top-in bottom-out, and bottom-in top-out.

6. Technical and Economic Efficiency


   Reduces feeder cross-sectional requirements and cuts material costs for system design.

Structure and Components

• Primary Coil: Handles high current loads and is constructed with high-strength insulating materials.
• Secondary Winding: Provides standard 5 A output, wound with low-impedance copper wire for stable performance.
• High-Voltage Current-Limiting Fuse: Installed at the primary side inlet, featuring fast-break functionality.
• Housing and Mounting Bracket: Metal or plastic enclosure with pre-drilled bolt holes for secure fixation inside switchgear cabinets.
• Terminal Blocks: Dedicated terminals for primary and secondary sides ensure reliable wiring connections.

Typical Applications

• Current measurement and protection in switchgear cabinets and low-voltage distribution boards
• Secondary circuit monitoring in substations
• Power metering and load monitoring in industrial automation systems
• Integration with Energy Management Systems (EMS) and Distribution Management Systems (DMS) platforms

Installation and Maintenance Guidelines

Environmental Requirements

• Ambient air temperature shall not exceed 40 ℃ (average temperature ≤ 35 ℃)
• Relative humidity ≤ 95 %
• Minimum operating temperature: -15 ℃

Wiring Precautions

• Use wires rated for the specified primary current for primary-side connections
• Maintain standard 5 A output on the secondary side and avoid short-circuiting the secondary circuit

Mounting Requirements

• Secure the enclosure to switchgear cabinets using supplied bolts to ensure vibration and dust resistance

Routine Inspection

• Inspect high-voltage current-limiting fuses and primary-side insulation condition every 6 months; replace components as needed

Replacement of Wear Parts

• Conduct preventive replacement of contactors and other consumable components before cumulative operations approach 2.5 million cycles
