Schneider AEG AS-P892-000 Processor Module
Schneider AEG AS-P892-000
AS‑P892‑000 is a core processor module developed by Schneider Electric for the Modicon M340 series PLCs. Adopting a modular design, it undertakes core tasks in industrial automation systems such as data acquisition, logic operation, motion control and multi-protocol communication. As the “brain” of the system, it centrally processes data from all I/O modules and enables coordinated system operation.
Key Technical Specifications
Power Supply: AC 220 V / 50 Hz (internally converted to 24 V DC)Operating Temperature: -20 ℃ to +60 ℃Dimensions: Approx. 18.5 × 10.2 × 6.4 cm, Net Weight: Approx. 1.2 kgI/O Capacity: Digital/analog inputs and relay/transistor outputs available based on specific configurations, supporting multi-channel I/O expansionCommunication Interfaces: Built-in Ethernet (10/100 Mbps) and industrial protocols including Modbus, Profinet, Ethernet/IPProtection Grade: IP20 (for cabinet installation), IP67 protection available for some models
Product Features
High-performance Processor: Multi-core CPU paired with large-capacity memory, meeting requirements for high-speed logic and motion control.Modular Design: Plug-and-play installation on DIN rails for convenient on-site expansion and maintenance.Multi-protocol Compatibility: Supports Ethernet, Modbus, Profinet, Ethernet/IP, facilitating interconnection with upper-level systems and field devices.Self-diagnosis & Fault Reporting: Built-in self-diagnostic function monitors module health in real time and reports fault information promptly.Flexible Configuration: Freely configure I/O types, communication parameters and security policies via Schneider SoMachine software.
Structure & Components
Processor Core Board: Integrates CPU, memory, storage and power management circuits.I/O Interface Board: Provides digital/analog inputs, relay/transistor outputs, as well as dedicated high-speed counting/pulse inputs.Communication Module: Equipped with Ethernet ports, serial ports and optional fieldbus (e.g., CAN, Profibus) modules.Heat Dissipation & Protection: Combined metal heat sink and plastic housing ensure reliable operation within a wide temperature range.
Typical Application Fields
Industrial Automation Control: Production lines, assembly robots, CNC machine tools, etc.Building & Facility Management: Centralized control of HVAC, lighting and security systems.Energy & Power: Wind power, photovoltaic inverters, distribution automation.Transportation: Real-time monitoring and protection of rail transit and locomotive traction systems.
Installation & Maintenance Guidelines
Installation Environment: Avoid locations with high temperature, humidity, strong vibration or heavy dust; recommended for use in dry, well-ventilated cabinets.Power Connection: Cut off power before wiring strictly; follow the wiring diagram in the product manual to ensure correct connection between AC power supply and internal DC conversion circuit.DIN Rail Fixing: Use standard DIN rail buckles to firmly insert the module and ensure buckles are locked in place to prevent loosening.Wiring Inspection: All I/O terminals must be wired according to labels to avoid module damage or signal errors caused by wrong connections.Software Configuration: Use Schneider SoMachine or EcoStruxure control software for project creation, hardware mapping and parameter setting, then download the configuration to the module.Regular Self-inspection: Utilize the module’s built-in diagnostic function to regularly read fault logs and operating status, and replace or repair abnormal components in a timely manner.Spare Parts Management: It is recommended to keep the same model modules or key I/O expansion cards on site to minimize downtime caused by faults.
————————————————————————————————————-
