Schneider AEG AM-S980-810 Network Interface Module
Schneider AEG AM-S980-810
The AM-S980-810 is a MAP 3.0 network interface module launched by Schneider Electric (formerly GE Modicon), designed to enable industrial Ethernet communication such as Ethernet/PROFINET in Modicon PLC systems. As a fieldbus/network expansion unit of the S980 series, this module is compatible with platforms like Modicon M340 and M580, delivering high-speed and reliable data exchange in fieldbus networks.
Key Technical Specifications
Model: AM-S980-810 (USPP)Interface Type: 10/100 Mbps Ethernet RJ45, supporting MAP 3.0 protocol stackPower Supply: 24 V DC (powered by internal power module)Operating Temperature: -25 °C to +70 °CDimension: DIN-rail mounted, 1 U wide (approx. 44 mm)Communication Protocols: Modbus TCP, EtherNet/IP, PROFINET, OPC UA (via MAP 3.0)Maximum Nodes: Supports up to 255 network nodes, with a single-unit bandwidth of up to 100 Mbps
Product Features
Plug-and-Play: Adopts standard DIN-rail structure for quick plugging and unplugging without additional wiring.Multi-protocol Compatibility: Built-in MAP 3.0 protocol stack, compatible with multiple industrial Ethernet protocols for easy system integration.High Reliability: Supports redundant networks, ring network protection and automatic failover to meet critical process control requirements.Security Features: Built-in security functions against unauthorized access, supporting user permission management and encrypted communication.Easy Diagnosis: Equipped with LED status indicators and online diagnostic information for convenient on-site maintenance.
Structure & Components
Enclosure: Metal protective case, complying with IEC 60529 IP20 protection class.Power Module: Internal 24 V DC conversion circuit for stable power supply.Network Interface Board: RJ45 port, optional fiber optic conversion, and MAP 3.0 protocol processing chip.Diagnostic/Indicator Lights: Power, communication and error indicator lights.Mounting Clips: DIN-rail clips for secure installation.
Typical Application Fields
Manufacturing Automation: High-speed data exchange between production line PLCs and upper-level systems (MES, SCADA).Process Control: Fieldbus network bridging in industries such as chemical, petroleum, food and beverage.Building & Facility Management: Ethernet connection between building automation systems and energy management platforms.Logistics & Warehousing: Real-time communication between AGVs, conveying systems and PLCs.
Installation Notes
Select a DIN-rail position and ensure sufficient space on both sides of the module for heat dissipation.Confirm power supply: Stable 24 V DC power supply to avoid voltage fluctuation.Network Wiring: Use shielded twisted pair (Cat 5e/6) compliant with industrial Ethernet standards and ensure proper grounding.Power off before plugging or unplugging to prevent transient current impact.After installation, configure network parameters via PLC programming software (e.g., Unity Pro) and check if LED indicators work normally.
Maintenance Recommendations
Regular Inspection: Check LED status, terminals and DIN-rail fixing screws to prevent loosening.Firmware Upgrade: Timely update according to MAP 3.0 firmware versions released by Schneider official to obtain new functions and security patches.Fault Diagnosis: Use the online diagnostic function of PLC software to view error codes; replace faulty RJ45 interface or power module when necessary.Environmental Monitoring: Keep working temperature and humidity within rated range, and avoid dust accumulation affecting heat dissipation.
————————————————————————————————————-
