Allen-Bradley 1336-B005-EAD
1. Primary Purpose
The Allen‑Bradley 1336‑B005‑EAD is an industrial‑grade AC drive designed to control the speed and torque of induction motors. It is widely used in industrial automation applications requiring precise motor control, such as conveyors, fans, pumps, and various automated production lines.
_______________________________________________________________________________________________________________________________
2. Technical Specifications
• Rated Power: Typically configured for around 5 HP (approximately 3.75 kW).• Rated Current: Approximately 9.6 Amps.
• Rated Voltage: Three‑phase input, commonly available in 380V / 415V / 460V configurations, 50/60Hz.
• Enclosure Type: Type E (NEMA Type 1), corresponding to IP20 protection, suitable for indoor installation.
• Frame Size: Size D (frame size code).
_______________________________________________________________________________________________________________________________
3. Key Features
• High‑efficiency control: Supports variable frequency speed regulation for smooth motor speed adjustment and improved energy efficiency. • Voltage stabilization: Provides stable output even during grid voltage fluctuations, protecting the motor.
• Parameterizable control: Offers multiple control modes and adjustable parameters to meet diverse industrial requirements.
• Compatibility: As part of the AB 1336 series, it provides excellent compatibility and versatility across various industrial scenarios.
_______________________________________________________________________________________________________________________________
4. Structure and Components
• Power input section: Handles three‑phase AC power input.• Power conversion section: Converts input voltage into the required voltage and frequency for motor operation.
• Control circuit: Includes a microprocessor, control panel, and communication interfaces such as a serial port.
• Output filter: Reduces harmonics in the output current to protect the motor.
_______________________________________________________________________________________________________________________________
5. Application Areas
• Manufacturing: Used for conveyor belts, packaging machinery, and other production line drives. • Environmental engineering: Applied in fluid control systems such as fans and pumps.
• Building facilities: Used to drive large HVAC system fans.
• Other automation systems: Any application requiring precise motor speed control.
_______________________________________________________________________________________________________________________________
6. Installation and Maintenance Recommendations
• Installation environment: With an IP20 rating, the drive must be installed in a dry indoor area, protected from water, dust, and corrosive gases.• Wiring requirements: Follow the electrical diagrams carefully to ensure correct input voltage, phase sequence, and grounding.
• Heat dissipation: Ensure adequate ventilation around the drive to prevent overheating.
• Maintenance: Regularly clean dust from the enclosure, inspect terminal connections, and perform internal cleaning if necessary to prevent moisture buildup.
————————————————————————————————————-
