Allen-Bradley 1336-C010-EAD-S Automation Module
Allen-Bradley 1336-C010-EAD-S
Key Functions
Provides variable frequency control to adjust motor speed, enabling soft start, braking, and torque control.
Provides variable frequency control to adjust motor speed, enabling soft start, braking, and torque control.
Product Positioning
Part of the 1336 series of low‑to‑medium power AC drives, suitable for general‑purpose mechanical applications.
Part of the 1336 series of low‑to‑medium power AC drives, suitable for general‑purpose mechanical applications.
____________________________________________________________________________________________________________________________________
Key Technical Specifications
| Parameter | Description |
|---|---|
| Power Range | The 1336 series typically covers 0.75 kW (1 HP) to 15 kW (20 HP). The exact power rating of the C010 variant depends on the full model number, but is generally between 1–5 HP. |
| Rated Current | Approximately 5–9 A (varies by power rating and voltage). |
| Rated Voltage | 380/415/460 VAC (common three‑phase voltages), 50/60 Hz (compatible with different grid frequencies). |
| Output Power | Typical output around 3.8–4.5 kVA, suitable for small‑to‑medium motors. |
| Frequency Range | 0.01 Hz to 500 Hz, providing a wide speed‑control range. |
| Efficiency | Up to 97% or higher (with IGBT power modules), meeting energy‑efficiency standards. |
| Protection Class | NEMA Type 1 (IP20), intended for indoor installation in non‑hazardous environments. |
| Control Modes | Supports V/F control, vector control (FOC), and multiple speed‑setting methods. |
Product Features
- Advanced IGBT Technology
Utilizes IGBT (Insulated Gate Bipolar Transistor) power modules for high efficiency, low losses, and fast response. -
Integrated Design
Typically available in 1U (1.75 inches) or Type D chassis (approximately 9 inches), allowing stacked mounting in control cabinets to save space. - Easy Commissioning Equipped with a digital display and fieldbus interface (such as DeviceNet) for convenient on‑site parameter setup and monitoring.
- Flexible Control
Supports multiple motor control modes, including basic V/F control and advanced vector control, to adapt to different load requirements.
____________________________________________________________________________________________________________________________________
Structure and Components
- Power Module
Internal IGBT power module responsible for high‑frequency switching of the motor supply. - Control Board
- Microprocessor (CPU) board that executes speed‑control algorithms and communication protocols.
- Cooling System
Air‑cooled or water‑cooled design to ensure stable long‑term operation. - Communication Interfaces
- Typically includes RJ45, RS‑485, or dedicated fieldbus ports (such as ControlNet).
____________________________________________________________________________________________________________________________________
Typical Applications
- Automated Production Lines
Packaging machinery, conveyors, injection molding machines, etc.= - Industrial Machinery CNC machines, punch presses, drilling machines, etc.
- HVAC Air‑conditioning compressors and fan drives.
- Oil and Gas / Petrochemical
Pumps, fans, centrifuges, and other process equipment.
____________________________________________________________________________________________________________________________________
Installation and Maintenance Recommendations
- Clearance Requirements
Follow Allen‑Bradley guidelines for adequate cooling space. A horizontal clearance of 4 inches (101.6 mm) between two 1336 drives is typically recommended, with 6 inches (152.4 mm) of clearance above and below the unit to ensure proper airflow. - Wiring Requirements
Ensure wiring complies with local electrical codes, using appropriate terminals and protective measures. - Maintenance
Periodically clean heat sinks, check fan operation, and monitor output current and temperature to prevent overload conditions.
————————————————————————————————————-
