Allen-Bradley 1336-MOD-KB005 Dynamic Braking Module
Allen-Bradley 1336-MOD-KB005
1. Overview
- Product Name: Allen‑Bradley 1336‑MOD‑KB005 Dynamic Brake
- Series: 1336 Series (commonly used in AC drive systems from 5HP to 20HP)
- Primary Function: Provides strong braking force to quickly stop motors, preventing inertia‑caused shocks and overshoot. Ideal for applications requiring fast response and high‑inertia loads.
_____________________________________________________________________________
2. Specifications
- Voltage Range: 380–750 VDC (varies by drive model; KB005 is typically used in medium‑to‑high power ranges).
- Power/Braking Capacity: 375W (approx. 0.5 HP), but actual braking force depends on the connected motor power and drive settings.
- Brake Type: Dynamic (resistor) braking.
- Control Method: Directly controlled by the Allen‑Bradley 1336 Series drive system; no additional control signals required.
_____________________________________________________________________________
3. Key Features
- High‑Efficiency Braking: Stops motors in very short times (typically less than 0.5 seconds), protecting mechanical structures.
- No Mechanical Wear: Unlike mechanical brakes, dynamic braking uses resistors to dissipate kinetic energy, eliminating wear issues.
- High Integration: Designed specifically for Allen‑Bradley 1336 Series drives, making integration into existing AB systems straightforward.
- Reliability: Industrial‑grade construction suitable for harsh factory environments.
_____________________________________________________________________________
4. Structure and Components
- Core Components: High‑power semiconductors (IGBTs or MOSFETs) that quickly absorb and dissipate regenerated motor energy.
- Cooling System: Built‑in heat sinks or fans to manage heat from high‑power resistive braking.
- Interface: Standard industrial plug‑in mounting for easy replacement and maintenance.
_____________________________________________________________________________
5. Application Areas
- Packaging Machinery: Such as winders and packaging lines that require rapid stops to prevent product damage.
- Textile Industry: Fast braking for warp and weft motors.
- Paper and Printing: High‑inertia paper transport and main press drives.
- Conveyor Systems: Conveyor belts and chain drives needing fast response.
- Other Automation Equipment: Reels, clutches, and other high‑speed braking components.
_____________________________________________________________________________
6. Installation and Maintenance
Installation: Typically installed directly into the Allen‑Bradley 1336 Series drive’s plug‑in box or rack. Ensure adequate ventilation for heat dissipation.Maintenance:
- Heat Dissipation Check: Regularly clean heat sinks and fans (if equipped) to prevent overheating.
- Electrical Connections: Ensure all connections are tight to avoid vibration‑induced loosening.
- Environmental Considerations: Avoid prolonged exposure to high temperatures or humidity; ensure compliance with industrial IP ratings.
————————————————————————————————————-
