Allen-Bradley 1336F-B020VAF

1. Overview

2. Specifications

• Model: 1336F‑B020VAF
• Power Rating: 20 HP
• Input Voltage: 460V AC (three‑phase)
• Output Frequency: 0–400 Hz
• Control Method: Vector Control
• Form Factor: Compact, modular design
• Communication: Ethernet/IP, DeviceNet, and other industrial protocols

_____________________________________________________________________________

3. Key Features

• High Power Density: Delivers 20 HP in a compact footprint, helping to save valuable cabinet space.
• Advanced Vector Control: Utilizes high‑precision vector control algorithms for fast response and accurate torque control.
• Modular Design: As part of the 1336 Plus II series, it offers modularity for easy integration with other I/O or functional modules.
• Flexible Communication: Supports multiple industrial Ethernet and fieldbus protocols, enabling seamless connection to modern industrial networks.

____________________________________________________________________________

4. Structure and Components

• Power Conversion Unit: Includes IGBT power devices that convert AC to DC and then invert it back to controlled AC.
• Control Board: Features embedded and DSP processors for executing vector control algorithms and handling communication protocols.
• Cooling System: High‑efficiency heat sinks or fans that maintain safe operating temperatures during high‑power operation.
• Communication Interface Module: Connects to PLCs, HMIs, or host computers for parameter configuration and real‑time monitoring.

_____________________________________________________________________________

5. Application Areas

• Packaging Machinery: Such as winders and packaging line conveyors.
• Textile Machinery: Used to drive winding and shuttle systems in textile production lines.
• Injection Molding Machinery: Controls the screw or injection units of injection molding machines.
• General Industrial Automation: Suitable for various industrial devices requiring variable‑speed control.

_____________________________________________________________________________

6. Installation and Maintenance

Installation Guidelines

• Electrical Connection: Ensure the input voltage matches the rated 460V, and correctly connect phases L1, L2, and L3.
• Grounding: Proper grounding is essential to prevent static buildup and electromagnetic interference.
• Ventilation: Install in a well‑ventilated area and avoid blocking fan inlets to ensure adequate cooling.

Maintenance Recommendations

• Regular Inspection: Check heat sinks and fans for dust accumulation, and clean vents to prevent overheating.
• Firmware Updates: Periodically check Rockwell’s official website for firmware updates to access new features and performance improvements.
• Troubleshooting: Use PLC or PC software to read drive diagnostics and address alarms or error codes promptly.
