Allen-Bradley 1336F-B050-AE-EN

1. Overview

2. Specifications

• Rated Current: 50 A
• Rated Power: 7.5 kW (approximately 10 HP)
• Input Voltage: 380 V ~ 480 V AC (3-phase)
• Output Voltage: 0 ~ 380 V ~ 480 V AC (3-phase)
• Control Method: Sensorless Vector
• Power Supply Mode: 24 V DC (internal power supply)
• Communication Interfaces: EtherNet/IP, DeviceNet, DH-485, Modbus RTU
• Ambient Temperature: –20 °C ~ +50 °C
• Protection Class: IP20 (indoor use)
• Installation Dimensions: Approximately 140 mm × 140 mm × 120 mm
• Weight: Approximately 3.2 kg

3. Product Features

• Sensorless Vector Control: It can achieve high-performance torque and speed control without the need for an external speed sensor.
• Modular Structure: It can be flexibly combined with other functional modules of the 1336 series, such as braking units and communication cards.
• Multi-Protocol Communication: Built-in EtherNet/IP, DeviceNet, DH-485, and Modbus RTU, facilitating integration into various fieldbus systems.
• Compact and Reliable: Small in size and light in weight, suitable for control cabinets with limited space.
• High Efficiency: Power factor > 0.95, complying with the IEC 61800-3-2 energy efficiency standard.
• Rich Protection Functions: Multiple protections including overcurrent, overvoltage, undervoltage, overheating, and phase sequence error.

4. Structure and Composition

• Power Module: Responsible for power conversion and output.
• Control Board: Implements control algorithms, parameter setting, and communication functions.
• Power Supply Module: Provides internal 24 V DC power supply.
• Heat Dissipation Device: Internal heat sinks and external heat dissipation holes ensure thermal management during long-term operation.
• Terminal Block: Input, output, control signal, and communication terminals with clear identification.
• Optional Braking Unit: The 1336-MOD-KB050 braking module can be optionally equipped to achieve rapid stopping.

5. Application Fields

• General Mechanical Drives: Such as conveyors, pumps, fans, and compressors.
• Packaging and Printing Equipment: Production lines that require smooth start-stop and precise speed control.
• Automated Assembly Lines: Cooperate with PLCs to achieve closed-loop control.
• Process Control: Fluid conveying systems in industries such as chemical engineering, food and beverage.
• Energy and Power: Small generator sets and variable frequency speed regulation systems.

6. Installation and Maintenance

Installation

1. Fix the drive in a control cabinet that meets the IEC 60204-1 standard to ensure unobstructed heat dissipation channels.
2. Correctly connect the power supply, output, control signal, and communication terminals according to the wiring diagram, and pay attention to the phase sequence and grounding.
3. If braking function is required, connect the braking unit according to the instruction manual and configure the parameters.

Commissioning

1. Before power-on, check whether all wiring is secure and free of short circuits.
2. Set basic parameters (rated current, acceleration/deceleration time, protection threshold) through HMI or PLC.
3. Conduct no-load testing, and connect the load only after confirming that the speed and torque curves meet expectations.

Daily Maintenance

1. Regularly check whether the terminal blocks are loose or corroded.
2. Clean the dust on the surface of the heat sink to maintain ventilation.
3. Monitor the internal temperature and operating current of the drive, and replace the power module damaged by overheating in a timely manner.
4. If a braking unit is used, check the status of the braking resistor and braking capacitor.

————————————————————————————————————-
