Allen-Bradley 20BH105A0ANNANC0

Overview

Key Technical Specifications

• Rated Current: 0 A ~ 105 A (with optional series including 140 A, 170 A, 205 A, etc.)
• Input Voltage: Three-phase 380 V / 400 V / 415 V (with optional 460 V / 480 V)
• Output Power: Approximately 7.5 kW ~ 22 kW (varies by specific current rating)
• Control Modes: V/Hz control, Vector Control (Field-Oriented Control, FOC)
• Display Interface: Full-digital LCD, providing operating parameters, fault codes, and setting menus
• Protection Functions: Multiple protections including overcurrent, overvoltage, undervoltage, overheating, short circuit, and phase sequence error
• Communication Interfaces: EtherNet/IP, DeviceNet, Modbus RTU (optional)

Product Features

• Modular Structure: The main unit, control board, terminal block, and display panel can be replaced independently, ensuring convenient maintenance.
• High-Efficiency IGBT Power Module: Reduces power consumption and improves heat dissipation efficiency.
• Flexible Frame Options: Standard C, D, E frames are available. Optional Filtered A/B frames can be selected to meet noise and filtering requirements.
• Compatibility with PowerFlex Software: Uses the configuration tools of PowerFlex 400/700/800, simplifying parameter setting and fault diagnosis.
• Full-Digital Display and Fault Diagnosis: Real-time display of key parameters such as motor speed, torque, and power. Fault codes help quickly locate issues.

Structure and Composition

• Drive Main Unit: Houses the IGBT power module and heat dissipation system.
• Control Board: Implements PWM generation, closed-loop control, and communication functions.
• Terminal Block: Provides connection points for power supply, output, and control signals.
• Display Panel (Optional): LCD for displaying operating status and parameters.
• Frame and Installation Accessories: Standard cabinet frames, bolts, brackets, etc.

Typical Application Areas

• Industrial Automation: Continuous operation equipment such as conveyors, compressors, pumps, and fans.
• Process Control: Scenarios requiring precise speed control in chemical, petroleum, food and beverage industries, etc.
• Machinery Manufacturing: CNC machine tools, packaging machinery, printing equipment, etc.
• Energy Systems: Speed control for fans and generator sets.

Installation and Maintenance Guidelines

• Installation: Select cabinets that meet IEC/EN standards to ensure proper ventilation and heat dissipation. Check phase sequence and grounding reliability before wiring.
• Commissioning: Use PowerFlex configuration software to set parameters. Conduct no-load operation checks first before connecting the load.
• Daily Maintenance: Regularly inspect the tightness of terminal blocks and the cleanliness of heat sinks. Retrieve fault logs through the LCD interface or communication ports, and replace faulty modules in a timely manner.
• Spare Parts Management: Due to the modular design, commonly used parts such as control boards, display panels, and terminal blocks can be stocked separately, reducing maintenance downtime.

————————————————————————————————————-
