ATLAS PF-4000-C-DN-HW Processor Module
ATLAS PF-4000-C-DN-HW
Product Overview
Key Specifications
|
Parameter
|
Specification
|
|---|---|
|
Product Model
|
PF-4000-C-DN-HW
|
|
Communication Interface
|
DeviceNet (DN)
|
|
Power Supply
|
AC 100–240V, 50/60Hz
|
|
Supported Tools
|
Compatible with Tensor series electric torque tools (e.g., Tensor ST, Tensor DS, etc.)
|
|
Control Modes
|
Torque Control, Angle Control, Composite Control, Slip/Loss/Under-torque Detection
|
|
Software Platform
|
Parameter setting and program writing via Power Focus software
|
|
Dimensions
|
319 mm (L) × 173 mm (W) × 415 mm (H)
|
|
Weight
|
Approx. 26.45 lbs (Approx. 12.19 kg)
|
_______________________________________________________________________________________________________
Product Features
- High-Precision Control: Supports high-precision tightening control at the 0.1% level to ensure the fastening quality of connectors.
- Multifunctional Modes: Integrates advanced functions such as torque control, angle control, slip/loss detection, enabling automatic re-tightening and data recording.
- Powerful Data Traceability: Real-time collection of tightening data, supporting storage of hundreds of sets of tightening programs for easy traceability and quality analysis.
- Industrial-Grade Communication: Equipped with a DeviceNet interface for easy integration into industrial automation systems.
_______________________________________________________________________________________________________
Structure and Composition
- Control Host: The core computing unit responsible for executing control algorithms and data processing.
- Communication Interface Module: Supports DeviceNet communication to connect PLCs and upper computers.
- Power Supply Module: Provides stable working power.
- Software Platform: Parameter setting, program writing, and data monitoring via Power Focus software.
_______________________________________________________________________________________________________
Application Fields
- Automotive Manufacturing: Automated assembly of engine, body, chassis and other components.
- Aerospace: Precision assembly of aero-engines and airframe structural parts.
- Railway: Assembly of train bodies and chassis.
- Other High-End Manufacturing: Fields such as high-precision machinery and medical equipment.
_______________________________________________________________________________________________________
Installation and Maintenance
- Installation Method: Standard industrial rail mounting or control cabinet embedded mounting.
- Maintenance Requirements: It is recommended to use in a dust-free and dry environment, and perform regular system inspection and calibration to ensure tightening precision.
- After-Sales Service: It is recommended to contact official authorized Atlas Copco distributors for installation, commissioning and maintenance services.
————————————————————————————————————-
