1. Overview

2. Specifications

• Model: PF4002-C-DN-HW
• Communication Interface: DeviceNet (DN)
• Compatible Tools: Tensor series intelligent electric torque tools
• Voltage Range: 120/180-240V AC
• Control Modes: Torque Control, Angle Control, Combined Control, Multi-step Sequence

_______________________________________________________________________________________________________

3. Product Features

• High-Precision Control: Supports torque control, angle control and combined control to ensure tightening quality.
• DeviceNet Communication: Realizes real-time data interaction with torque tools, PLC and other equipment through DeviceNet bus.
• Data Traceability: Equipped with real-time data collection, alarm log, production statistics and other functions to support process traceability.
• Modular Design: Compact structure, easy to integrate into existing assembly lines.

_______________________________________________________________________________________________________

4. Structure and Composition

• Control Unit: The core computing and control module, responsible for processing sensor data from tools.
• Communication Module: Communication interface supporting DeviceNet bus.
• Power Supply Module: Provides stable power supply for the system.
• IO Interface: Used to connect external sensors or actuators.

_______________________________________________________________________________________________________

5. Application Fields

• Automotive Manufacturing: Precision tightening of body, chassis and engine components.
• Aerospace: High-precision assembly of engine components and body structures.
• Mechanical Manufacturing: Assembly of precision mechanical components.
• High-End Electronics: Assembly of electronic components with high torque requirements.

_______________________________________________________________________________________________________

6. Installation and Maintenance

Installation

Maintenance
