ATLAS PF3107-C-EIP-HW Controller Module
ATLAS PF3107-C-EIP-HW
Product Overview
The PF3107-C-EIP-HW is a compact controller in the Power Focus 3100 series, specifically designed for automated assembly lines and high-precision manufacturing industries. It is mainly used to control and drive Atlas Copco’s Tensor series (Tensor 3 to Tensor 7) electric tightening tools, supporting multiple industrial communication protocols to achieve high-precision and traceable tightening operations.
_______________________________________________________________________________________________________
Key Specifications
|
Specification
|
Details
|
|---|---|
|
Model
|
PF3107-C-EIP-HW
|
|
Input Voltage
|
90-120V / 180-240V AC, 50/60Hz (compatible with single-phase and three-phase power supplies)
|
|
Output Power
|
Approx. 300W (for driving electric tools)
|
|
Supported Tools
|
Tensor 3 to Tensor 7 series electric tightening tools
|
|
Communication Interface
|
EIP (EtherNet/IP) industrial Ethernet protocol
|
|
Control Functions
|
Torque control, angle control, combination control, multi-step process support
|
|
Output Signals
|
Typically supports Digital Output (DO) and Analog Output (AO) for controlling valves or external devices
|
_______________________________________________________________________________________________________
Product Features
High-Precision Control
Supports Atlas Copco’s Torque Pro 4.0 software, enabling extremely high torque accuracy and angle accuracy to meet strict quality control requirements.
Compact Design
Compared with large control cabinets, the PF3107-C series adopts a compact design, making it more suitable for installation in automated workstations or independent workstations with limited space.
Powerful Communication Capability
Adopting the EtherNet/IP (EIP) protocol, it can be easily integrated into the industrial Ethernet to achieve real-time data interaction with PLCs or upper computers.
Modular Functionality
Supports a variety of optional modules (such as valve control modules, sensor input modules), which can be flexibly configured according to actual needs.
_______________________________________________________________________________________________________
Structure and Composition
- Control Host (CPU): Responsible for instruction processing and communication management.
- Power Module: Includes motor drive circuit (IGBT), rectifier circuit, etc.
- Communication Interface Board: Used for EtherNet/IP communication.
- Connection Terminals: For connecting power supply, tools, sensors and actuators.
- Display/Indicator Lights: For status display (may vary according to specific configurations).
_______________________________________________________________________________________________________
Application Fields
- Automotive Manufacturing: Body welding points, engine assembly, door assembly, etc.
- Aerospace: Aircraft fuselage structural parts, engine component assembly.
- Electronic Appliances: High-precision motor assembly, chassis assembly.
- Heavy Machinery: Assembly of key components of construction machinery and agricultural machinery.
_______________________________________________________________________________________________________
Installation and Maintenance
Installation Requirements
It is recommended to install in a well-ventilated environment to ensure that the power wiring complies with local electrical standards (such as IEC standards). Usually adopts DIN rail mounting method.
Maintenance Recommendations
Regularly check the status of power connections, communication cables and tool sensor wiring; keep the environment clean to avoid dust entering internal electronic components.
————————————————————————————————————-
