ATLAS PF3009-C-DN-HW Digital Output Module
ATLAS PF3009-C-DN-HW
1. Overview
ATLAS PF3009-C-DN-HW is a core product in the ATLAS COPCO Power Focus 3000 series, specifically designed for automated assembly applications in the medium to high torque range. It is mainly used to drive electric tightening tools of the Tensor series (such as ST, S4, S7, S9, etc.), providing precise torque and angle control.
_______________________________________________________________________________________________________
2. Specifications
Model Meaning
- PF3009: A high-power model in the Power Focus 3000 series.
- C: Indicates the standard control version.
- DN: Equipped with a DeviceNet communication interface.
- HW: Hardware version identifier.
_______________________________________________________________________________________________________
Key Parameters
- Power Supply: AC 100–240V, 50/60Hz
- Communication Protocols: DeviceNet (main), Ethernet, RS232, Digital I/O
- Control Modes: Supports torque control, angle control, and composite control
_______________________________________________________________________________________________________
3. Product Features
- Highly Integrated: Integrates motor control and tightening logic to simplify assembly line design.
- High Precision: Supports storage of hundreds of programs, providing fine-grained torque/angle settings.
- Fault Detection: Built-in abnormal detection algorithms for thread slipping, missing tightening, under-torque, etc., with automatic re-tightening function to improve assembly quality.
_______________________________________________________________________________________________________
4. Structure and Composition
- Control Unit: Core circuit board responsible for signal processing and motor driving.
- Communication Module: DeviceNet interface module supporting fieldbus communication.
- Input/Output Terminals: Used to connect external sensors or actuators.
_______________________________________________________________________________________________________
5. Application Fields
It is mainly applied in industrial automated production lines with strict requirements on tightening quality, such as automobile manufacturing (body welding, engine assembly), aerospace, and electronic and electrical assembly.
6. Installation and Maintenance
Installation
Usually installed on standard industrial guide rails or embedded in control cabinets, which can be used after connecting power and communication cables.
Maintenance
Regularly check the connection terminals, clean the heat sink, and perform firmware upgrades and parameter calibration when necessary.
————————————————————————————————————-
