ATLAS PF3109-C-HW Drive Controller
ATLAS PF3109-C-HW
1. Overview
PF3109-C-HW is a “medium and high-power intelligent electric tool drive controller”. As the core product of the Power Focus 3100 series, it is mainly responsible for controlling the precise torque, angle, and multi-stage tightening process of Tensor series electric tightening tools.
___________________________________________________________________________________________________________________________
2. Core Specifications
|
Specification Type
|
Specific Value/Range
|
Description
|
|---|---|---|
|
Power & Voltage
|
90-120V/100-240V AC, Power approx. 300W
|
Compatible with global power grids, supporting a wide voltage range
|
|
Compatible Tools
|
Tensor 8-9 Nut Runner
|
Specialized designed for 8-9 series nut runners
|
|
Control Precision
|
High-precision torque and angle control
|
Supports torque, angle, and multi-stage tightening functions
|
|
Communication Interface
|
Standard Control Version (C), no built-in industrial bus
|
Usually needs to be combined with external modules (such as G-DN) to achieve DeviceNet communication
|
___________________________________________________________________________________________________________________________
3. Product Features
- High-Precision Control: It can achieve precise control of torque, angle, and composite tightening processes, ensuring the quality of bolt fastening.
- Modular Design: Adopting the standard control version (C), it can be flexibly combined with external communication modules (such as DeviceNet, Ethernet modules) as needed.
- Global Compatibility: Supports a wide voltage range of 100-240V, suitable for global manufacturing environments.
___________________________________________________________________________________________________________________________
4. Structure & Composition
PF3109-C-HW is mainly composed of the following parts:
- Power Module: Responsible for receiving external power and converting it into internal working voltage.
- Control Core Chip: Executes Torque/Angle algorithms to control motor output.
- Communication Interface: Although it is a standard version, its physical structure retains a slot for connecting with communication modules (such as G-DN).
- Heat Dissipation Device: Due to the high working power, it is usually equipped with heat sinks or fans inside to ensure stability.
___________________________________________________________________________________________________________________________
5. Application Fields
PF3109-C-HW is usually applied in the following fields:
- Automotive Manufacturing: Engine assembly, chassis installation, door assembly and other links that require high-precision fastening.
- New Energy Vehicles: Battery module assembly and motor installation.
- Construction Machinery: High-load fastening of large bolts.
- Home Appliance Manufacturing: Assembly lines that require precise torque control.
6. Installation & Maintenance
- Installation Method: Usually adopts DIN rail installation or panel embedded installation. During installation, ensure that the connections with power lines and signal lines are firm, and maintain good plug-in contact with external communication modules (such as G-DN).
- Maintenance Recommendations: Regularly check whether the heat dissipation system is working normally, clean dust, and ensure that the internal temperature is controlled within a safe range. In addition, check the connection status of the communication interface to prevent signal transmission interruption caused by poor plug-in.
————————————————————————————————————-
