ATLAS PF3109-G-HW Drive Module
ATLAS PF3109-G-HW
1. Product Overview
The PF3109-G-HW is part of Atlas Copco’s Tensor series drives, specifically the 8/9 series. This series of drives is designed for high-power applications, capable of delivering 300W of power output and compatible with 3-phase/4-pole AC 380V motors. It integrates advanced control technology to meet the high-performance requirements of industrial automation equipment.
___________________________________________________________________________________________________________________________
2. Key Technical Parameters
|
Parameter
|
Specific Specifications
|
|---|---|
|
Power
|
300W
|
|
Control System
|
Tensor 8/9 (8/9 Series Controller)
|
|
Compatible Motor
|
3-phase / 4-pole
|
|
Rated Power
|
300W
|
|
Rated Current
|
8A
|
|
Operating Frequency
|
50/60Hz
|
|
Power Input
|
380V AC
|
|
Speed Range
|
0-6000 RPM
|
|
Weight
|
Approx. 5.4kg
|
|
Operating Temperature
|
0-40℃
|
|
Protection Class
|
IP21
|
|
Protection Measures
|
Overload Protection, Overvoltage Protection, Short Circuit Protection, Overheating Protection, Ground Disconnection Protection, Phase Sequence Error Protection, Undervoltage Protection
|
3. Product Features
- High-Precision Positioning: Adopts the latest vector control technology, providing extremely high positioning accuracy and dynamic response performance to meet the precise control needs of high-end equipment.
- High Reliability: Built-in multiple safety protection functions (such as overload, overvoltage, short circuit, etc.), effectively preventing equipment damage and ensuring safe and stable operation.
- Flexibility: Supports multiple communication protocols (such as CANopen), facilitating seamless integration with PLC or CNC control systems and adapting to diverse automation scenarios.
- Easy Maintenance: Modular design simplifies quick replacement and maintenance of components, reducing downtime and maintenance costs.
___________________________________________________________________________________________________________________________
4. Structure and Composition
The PF3109-G-HW drive is mainly composed of the following components, with a reasonable structure and stable performance:
- Power Module: The core part responsible for motor drive, ensuring stable power output.
- Control Unit: Realizes precise control of the motor, ensuring accurate operation and response.
- Cooling System: Built-in heat sink or fan for heat dissipation, preventing equipment overheating due to long-term operation.
- Communication Interface: Used to connect CNC controllers or PLCs, enabling data transmission and control.
___________________________________________________________________________________________________________________________
5. Application Fields
- CNC Machine Tools: Used to drive the spindles of CNC lathes and milling machines, ensuring high-precision and high-efficiency processing.
- Industrial Robots: Serves as the spindle drive system, providing stable power support for robot movements and operations.
- Automation Equipment: Suitable for automated production lines with high-precision requirements, improving production efficiency and product quality.
___________________________________________________________________________________________________________________________
6. Installation and Maintenance
Installation
It should be fixed on the frame to ensure good ventilation and heat dissipation. Avoid direct sunlight and humid environments to prevent equipment failure caused by harsh conditions.
Maintenance
Regularly check the dust on the heat sink and the tightness of wire connections. Pay attention to monitoring abnormal noise or overheating during operation, and handle potential problems in a timely manner to extend the service life of the equipment.
————————————————————————————————————-
