ATLAS PF3109GPBHW Automated Processor Module
ATLAS PF3109GPBHW
1. Overview & Positioning
Product Positioning: Designed for automated tightening applications in the medium-to-high torque range (e.g., M8/M9 bolts), widely used in assembly lines with high precision and critical quality requirements (such as automotive chassis and body assembly).
Core Function: Controls the torque, tightening angle and tightening quality of bolts to ensure the connection reliability of fasteners.
_______________________________________________________________________________________________________
2. Key Specifications
Power & Voltage: High-power model, compatible with high-torque electric tools, supporting industrial standard voltages (220V/380V).
Communication Interfaces:
- DeviceNet (DN): Facilitates integration with fieldbus networks and supports real-time data exchange.
- Optional Expansion: Supports industrial protocols such as PROFIBUS and PROFINET.
Tightening Modes: Torque control, angle control, multi-stage control, composite control (e.g., torque + angle).
_______________________________________________________________________________________________________
3. Product Features
- High Integration: Integrates multiple communication interfaces and advanced control algorithms to reduce the complexity of external wiring.
- Precise Control: Equipped with high-precision sensors and control algorithms, enabling extremely high tightening accuracy.
- Data Tracking: Supports detailed tightening process records (Torque Curve, Angle Curve) for easy quality auditing.
- User Interface: Usually equipped with a clear operation interface (some models have a graphical interface), supporting parameter setting and fault diagnosis.
_______________________________________________________________________________________________________
4. Structure & Composition
- Control Unit: Core control circuit board responsible for executing control commands.
- Communication Module: Such as DeviceNet module for network communication.
- Input/Output Interfaces: Connect tools, sensors and external PLC/systems.
- Heat Dissipation System: Good heat dissipation design (heat sink or fan) is required for high-power operation.
_______________________________________________________________________________________________________
5. Application Fields
- Automotive Industry: Bolt assembly of engines, chassis and vehicle bodies.
- Aerospace: High-precision tightening of key structural components.
- Rail Transit: Assembly of vehicle bodies and chassis.
- Other Heavy Industries: Such as high-strength connections in ships and construction machinery.
_______________________________________________________________________________________________________
6. Installation & Maintenance
Installation: Usually installed in industrial control cabinets or fieldbus panels, and must be fixed on a stable base to ensure reliable grounding.
Maintenance:
- Regularly inspect connecting harnesses and connectors.
- Clean the heat sink to ensure unobstructed heat dissipation.
- Perform regular system calibration (such as torque calibration).
————————————————————————————————————-
