ATLAS PF4002-C-HU Transmission Module
ATLAS PF4002-C-HU
1. Overview
ATLAS PF4002-C-HU is a high-precision tightening controller (Controller) in the ATLAS COPCO Power Focus 4000 series, specifically designed for the automotive manufacturing industry, aerospace, and other high-end manufacturing fields that require strict quality control. This model is usually equipped with a PROFIBUS (HU) communication interface (or compatible with other industrial fieldbuses) for integration into industrial automation systems.
_______________________________________________________________________________________________________
Core Functions
- Multi-mode Control: Supports torque control, angle control (rotation angle control), and combined control (torque + angle).
- Traceability: Equipped with powerful data recording and analysis functions, meeting the requirements of quality management systems such as ISO 9001.
- Automation Integration: Seamless communication with PLC and upper-level systems through PROFIBUS to realize full automatic assembly line control.
_______________________________________________________________________________________________________
2. Key Technical Specifications
|
Parameter Category
|
Specific Indicators
|
|---|---|
|
Model
|
PF4002-C-HU
|
|
Communication Interface
|
PROFIBUS (HU); Compatible with EtherNet/IP, PROFINET, etc.
|
|
Control Mode
|
Torque, Angle, Combination, Multi-step Sequence Control
|
|
Tool Compatibility
|
Compatible with ATLAS COPCO Tensor series electric torque tools
|
|
Data Function
|
Real-time data collection, production statistics, alarm logs, data traceability
|
|
Operating Environment
|
Industrial-grade environment; Wide adaptability to temperature and humidity ranges
|
|
Display Mode
|
Touchscreen graphical interface (depending on specific configuration)
|
_______________________________________________________________________________________________________
3. Key Features
Highly Integrated Automation Solution
Digitize and automate the traditional torque/angle tightening process, greatly improving assembly accuracy and efficiency.
Intelligent Tightening Control
- Multi-axis Linkage: Supports simultaneous control of multiple axes to realize complex assembly processes.
- Self-learning Function: Control programs can be automatically generated through learning operations.
Data-driven Quality Management
- Record the torque and angle curves of each tightening process through high-speed data collection.
- Supports data export to MES/ERP systems to achieve full-process quality traceability.
Powerful Fieldbus Compatibility
In addition to PROFIBUS, some models support EtherNet/IP, PROFINET, etc., adapting to automation systems of different manufacturers.
_______________________________________________________________________________________________________
4. Structure & Composition
Main Control Module (CPU)
Responsible for overall logic operation, data processing and communication management.
Input/Output (I/O) Module
- Digital Output: Controls the start/stop and direction change of tools.
- Analog Input: Receives torque/angle sensor signals.
_______________________________________________________________________________________________________
Communication Interface Module
PROFIBUS Interface: Used for high-speed data exchange with upper-level PLC.
Display and Operation Panel
Touchscreen or keyboard panel for local parameter setting and operation monitoring.
Power Supply Module
Provides stable industrial-grade power supply.
————————————————————————————————————-
