ATLAS PF4000-C-HW Control Board Module
ATLAS PF4000-C-HW
Specifications & Technical Parameters
|
Parameter
|
Description
|
|---|---|
|
Power
|
300W (Standard Configuration)
|
|
Voltage Range
|
AC 90–240V, 50/60Hz, supporting wide-range power supply
|
|
Control Mode
|
Torque Control, Angle Control, Compound Control (Torque+Angle)
|
|
Communication Interface
|
Industrial Ethernet, RS485/RS232 Serial Port, CAN Bus, USB Interface, etc.
|
|
Input Current
|
Typically 4-8A, depending on specific configuration and working voltage
|
|
Weight
|
Approx. 12–16kg (depending on configuration and accessories)
|
Product Features
- High-Precision Torque Control: Adopts advanced closed-loop control technology to achieve extremely precise torque output, ensuring assembly quality.
- Multi-Mode Control: Supports torque, angle, and compound control modes, which can be flexibly switched according to process requirements.
- Modular Design: Supports pluggable modules (such as RBU modules) for tool parameter setting and maintenance, facilitating on-site quick debugging.
- Strong Communication Capability: Compatible with multiple industrial protocols, enabling easy integration into the workshop’s DNC (Distributed Numerical Control) system or process management system.
- Graphical Operation Interface: Equipped with a user-friendly display screen and operation panel, supporting user programming and multi-process step switching.
___________________________________________________________________________________________________________________________
Structure & Composition
- Control Unit: The core computing and control module, responsible for signal collection, algorithm processing, and execution command output.
- Input Power Module: Responsible for receiving external power and converting it into the DC voltage required internally.
- Communication Interface Board: A hardware circuit board including Ethernet, CAN, USB and other interfaces.
- Display & Operation Panel: Includes a liquid crystal display (LCD) and buttons for on-site operation and parameter display.
- Input/Output Ports: Used to connect external sensors, light indicators, and other external control devices.
___________________________________________________________________________________________________________________________
Application Fields
|
Industry
|
Application Scenarios
|
|---|---|
|
Automotive Manufacturing
|
Body Welding, Chassis Assembly, Engine Final Assembly, etc.
|
|
Aerospace
|
Wing Assembly, Engine Assembly, Fuselage Structure Assembly
|
|
Railway & Rail Transit
|
Car Body Welding, Track Fastening, Bridge Assembly
|
|
Marine Manufacturing
|
Hull Structure Assembly, Pipeline Fastening
|
|
Large-Scale Equipment
|
Pipeline and Bolt Assembly of Wind Turbines, Nuclear Power Plants, Petrochemical Equipment
|
Installation & Maintenance
Installation
- Location Selection: Install in a well-ventilated and dry environment, avoiding direct sunlight and high-temperature conditions.
- Power Connection: Connect the appropriate voltage (90–240V) according to the model requirements, and pay attention to the load capacity of the power cord.
- Ground Protection: Ensure the control cabinet has good grounding to prevent electromagnetic interference and electric shock risks.
___________________________________________________________________________________________________________________________
Maintenance
- Regular Cleaning: Remove internal dust and dirt to keep the cooling fan running normally.
- Connection Inspection: Regularly check the connection status of communication cables, sensor cables, and power cords to prevent loosening.
- Software Upgrade: Regularly check for firmware or software updates released by Atlas Copco official, and upgrade the control system to obtain better performance and compatibility.
- Spare Parts Replacement: It is recommended to equip spare power modules, communication boards, and fans for quick replacement of faulty components.
