ATLAS PF4000-C-PN-HW Core Unit
ATLAS PF4000-C-PN-HW
1. Overview
2. Technical Specifications
|
Item
|
Specifications
|
|---|---|
|
Model
|
PF 4000-C-PN-HW
|
|
Order Number
|
8433714805
|
|
Dimensions
|
Approx. 48 cm x 44 cm x 27 cm
|
|
Weight
|
Approx. 12.3 kg
|
|
Operating Temperature
|
Approx. 41°F to 104°F (Approx. 5°C to 40°C)
|
|
Communication Interfaces
|
Built-in PROFINET interface (PN); compatible with EtherNet/IP, Modbus TCP/IP, USB and RS232
|
|
Language Support
|
Supports multi-language display, including Chinese
|
___________________________________________________________________________________________________________________________
3. Product Features
- High-Precision Control: Integrated with torque control, motor management and fault detection functions, it effectively ensures the consistency and reliability of tightening quality, reducing assembly errors.
- Multi-Protocol Compatibility: In addition to PROFINET, it is also compatible with EtherNet/IP and Modbus TCP/IP, which can be seamlessly adapted to various industrial network environments and improve production line connectivity.
- Compact Design: With a compact structure and moderate weight, it is easy to install and integrate into existing production lines, saving installation space and reducing integration costs.
___________________________________________________________________________________________________________________________
4. Structure and Composition
- Main Control Unit: As the core component, the main control board is responsible for receiving and executing various control commands to ensure the stable operation of the controller.
- Communication Module: It includes PROFINET port and other network interfaces, which is the key part for the controller to realize data transmission and communication with other devices.
- Power Supply Module: Provides stable and reliable power for the internal circuits of the controller, ensuring the normal operation of all components.
- Mounting Base: Used to fix and install the controller, which has good stability and can adapt to the industrial working environment.
___________________________________________________________________________________________________________________________
5. Application Fields
- Automotive Manufacturing: Widely used in automated tightening operations such as body assembly and engine assembly, improving assembly efficiency and quality.
- Electronic Products: Suitable for precision assembly of electronic products such as mobile phones and computers, meeting the high-precision tightening requirements of small components.
- Machinery Manufacturing: It is widely applied in the assembly lines of mechanical equipment and mold manufacturing, realizing automated and standardized assembly operations.
- Aerospace: Used in high-demand structural assembly fields, ensuring the safety and stability of aerospace components through high-precision tightening control.
