ATLAS PF6000LV

1. Product Overview

2. Key Technical Specifications

• Power Supply Voltage: Supports 24V DC or 48V DC.
• Tool Compatibility: Exclusively designed for Atlas Copco’s low-voltage tool series.
• Communication Interfaces:

  Control Modes: Supports multiple assembly strategies including torque control, angle control, torque-angle combined control, and impulse control.

  • SmartScreen Touchscreen: Displays real-time data and system status.
  • SmartSet Programming Interface: Parameter setting via PC software.
  • Open Protocol API: Supports industry-standard protocols such as OPC-UA, Ethernet/IP, and PROFINET, enabling seamless integration with PLC/SCADA systems.

___________________________________________________________________________________________________________________________

3. Product Features

• High-Precision Control: Achieves high-precision control of ±0.5% or ±0.2 Nm through precision torque sensors and real-time data acquisition.
• Multiple Assembly Strategies: Flexibly meets the needs of different assembly process requirements.
• Easy Integration: Supports multiple installation methods (desktop, wall-mounted, or embedded) to adapt to different production line layouts.
• Data-Driven: Equipped with powerful data collection and analysis capabilities, providing support for quality traceability and process optimization.

___________________________________________________________________________________________________________________________

4. Structure and Composition

• Display Module: SmartScreen touch-type color graphical user interface, providing an intuitive operating experience.
• Communication Module: Built-in network interfaces such as Ethernet/IP, PROFINET, and Modbus/TCP, supporting cloud data reporting.
• I/O Module: Can connect various sensors, PLCs, or upper computers to achieve closed-loop control.

___________________________________________________________________________________________________________________________

5. Application Fields

• Automotive Manufacturing: Bolt connection of engines, chassis, and body structural components.
• Aerospace: Precision assembly of aircraft structural components.
• Heavy Machinery: Assembly of electrical cabinets and large-scale equipment.
• Electronics and Electrical: Assembly of transformers, generators, and aero-engine components.
• Home Appliances and Electronics: Screw fastening for products such as televisions and air conditioners.

————————————————————————————————————-
