ATLAS PF4002-C-EIP-HW Controller Module
ATLAS PF4002-C-EIP-HW
1. Product Overview
2. Core Specifications
|
Specification
|
Description
|
|---|---|
|
Model
|
PF4002-C-EIP-HW
|
|
Communication Protocol
|
EtherNet/IP (EIP)
|
|
Control Mode
|
Torque Control, Angle Control, Combined Control, Joint Angle Control, Sequence Control
|
|
Sensor Support
|
12V Torque Sensor, CAN Bus Sensor
|
|
Data Functions
|
Real-time Data Collection, Traceability, Alarm Log, Production Statistics, Process Monitoring
|
|
Scalability
|
Supports Multi-channel expansion, suitable for multi-station operations
|
_______________________________________________________________________________________________________
3. Product Features
- Multi-control Mode Support: Compatible with angle control, torque control, combined control and multi-step sequence control, which can adapt to complex assembly processes.
- Industrial-grade Communication: Integrated with EtherNet/IP interface, supporting seamless connection with upper computers such as PLC and MES systems to realize Industrial Internet of Things (IIoT).
- High Precision and Traceability: Equipped with high-precision control capability and powerful data recording function, meeting the requirements of high-reliability assembly.
- Modular and Compact Design: The hardware structure is compact, easy to install in the control cabinet, and supports highly scalable multi-station process control.
_______________________________________________________________________________________________________
4. Structure and Composition
- Main Controller: The main body of PF4002-C-EIP-HW, responsible for command calculation and execution.
- Connecting Harness: Used to connect torque sensors, actuators and upper computers.
- Software Platform: Usually matched with Atlas Copco Power Focus 4.0 software platform (including PC terminal and HMI terminal) for parameter setting, data monitoring and system debugging.
_______________________________________________________________________________________________________
5. Main Application Fields
- Aerospace Industry: Bolt connection of aircraft structural components and assembly of composite material connections.
- Automotive Manufacturing: High-precision tightening of key components such as engines, gearboxes and chassis.
- Railway and Construction Machinery: Assembly process control of large equipment components.
- New Energy Field: Such as bolt connection control of new energy vehicle power battery modules.
_______________________________________________________________________________________________________
6. Installation and Maintenance Recommendations
Installation
- Environmental Requirements: Ensure that the installation environment meets industrial equipment standards (such as temperature, humidity, ventilation), and avoid high humidity or strong corrosive environments.
- Communication Connection: Select the appropriate industrial bus interface (such as EIP, PROFINET, etc.) for wiring according to on-site needs to ensure reliable connection.
- Power Requirements: Use a regulated power supply that meets the specifications to avoid equipment failure caused by voltage fluctuations.
Maintenance
- Regular Inspection: Regularly check the cable connection status and interfaces to prevent loosening or oxidation.
- Firmware Update: Pay attention to the firmware upgrades released by Atlas Copco official, and regularly update software and firmware to obtain new functions and bug fixes.
- Data Backup: Regularly back up parameter settings and production data to prevent data loss caused by system failures.
————————————————————————————————————-
