BENTLY NEVADA 3500-22M Data Interface (TDI) Module
BENTLY NEVADA 3500-22M
1. Overview
The BENTLY 3500-22M is an important Transient Data Interface (TDI) module of the Bently Nevada 3500 series monitoring system. It is specifically designed to capture and record transient data (such as shocks, instantaneous vibration peaks, etc.) of rotating machinery (such as turbines, compressors, pumps, etc.), facilitating accurate fault diagnosis and preventive maintenance.
______________________________________________________________________________________________
2. Parameters and Specifications
- Measurement Range: 0-1000mm/s (or corresponding acceleration range).
- Sampling Rate: Optional 25.6 kHz, 51.2 kHz, 102.4 kHz; some high-end models support up to 100 kHz or higher.
- Resolution: Up to 24 bits.
- Power Requirement: 24 VDC, power consumption ranges from approximately 7.7W to 25W.
- Interfaces: Supports BNC input; network communication interfaces include Ethernet (10Base-T/100Base-TX/100Base-FX) and RS-485.
______________________________________________________________________________________________
3. Product Features
- High-Precision Measurement: Adopts advanced sensor technology and signal processing algorithms to ensure data accuracy.
- High Reliability: Designed in compliance with international standards such as API, CSA, FM, GOST, ATEX, and CE; certified by DNV, Class NK marine certification and TÜV SIL 2 functional safety certification, suitable for harsh industrial environments.
- Modular and Redundant Design: Modular design facilitates installation and maintenance; supports redundant configuration to ensure no loss of critical data.
- Flexible Configuration: The number of channels (single-channel or multi-channel), sampling rate, and communication protocol can be configured according to different monitoring needs.
______________________________________________________________________________________________
4. Structure and Composition
- Rack-Mounted Installation: The module adopts a half-height or full-height module design, usually installed in a dedicated 3500 rack, supporting rack-mounted power supply (AC/DC combination).
- Input/Output Interfaces: Equipped with BNC input interfaces for connecting sensors and network interfaces for data transmission; some models support RS-485 serial communication.
______________________________________________________________________________________________
5. Application Fields
- Power Industry: Monitoring of generators and steam turbines.
- Oil and Gas: Monitoring of compressors and pump stations.
- Aerospace: Monitoring of engines and key mechanical components.
- Offshore Platforms: Offshore petrochemical and offshore power generation platforms.
______________________________________________________________________________________________
6. Installation and Maintenance
Installation
It is usually installed in the 3500 system rack. Attention should be paid to the power supply method (supports AC/DC combination) and the matching of rack slots. During installation, ensure that the ambient temperature (-40°C to +70°C) and protection level (IP65/IP67) meet on-site requirements.
Maintenance
The module is designed for easy maintenance and supports hot-swap. It is recommended to regularly check the data storage status and network communication, and ensure that the software and firmware versions are up-to-date.
————————————————————————————————————-
