GE DS200PTBAG1A printed circuit board

Short Description:

The GE DS200PTBAG1A is a printed circuit board (PCB) product designed by General Electric (GE) for the Mark V turbine control system series, categorized as a protection terminal module.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: GE

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

GE DS200PTBAG1A

1. Product Overview

The GE DS200PTBAG1A is a printed circuit board (PCB) product designed by General Electric (GE) for the Mark V turbine control system series, categorized as a protection terminal module. As a core component of the GE Speedtronic control system, it is dedicated to the management and control of GE-compatible steam and gas turbine automation equipment, delivering stable and reliable operational control for industrial turbine systems.

2. Technical Specifications

Parameter Item	Specification
Product Part Number	DS200PTBAG1A
Manufacturer	General Electric (GE)
Series	Mark V
Product Category	Protection Terminal Module
Unused Connector	JJS/T Connector
Mark V Series Grouping	Group 1
Board Type	Multi-layer PCB board equipped with industrial-grade analog and digital components

3. Structure and Composition

3.1 Physical Structure

Terminal Blocks: 2 terminal blocks in total, each equipped with 72 signal terminals, featuring 144 signal terminals in total
Connectors: 3 ten-pin connectors with IDs JJR, JJT and JJS respectively
Signal Terminal Posts: Equipped with terminal posts for 6 signal lines
Dimensions: 3 inches in height, 11.5 inches in width
Mounting Holes: One mounting hole at each corner for fixing the board to the internal rack of the drive device
Weight: Approximately 2 pounds

3.2 On-board Components

Removable jumpers for controlling the standard buzzer
Premium wear-resistant protective coating
Indispensable for the normal operation of TCEB and TCTG boards

4. Product Features

Feature	Description
Multi-functional Protection	As a professional protection terminal module, it guarantees the reliable operation of various mechanical equipment and industrial processes, avoiding abnormal system operation caused by parameter deviation or equipment failure.
Fast Connection	Equipped with JJS/T connectors to realize fast and stable connection within the system, greatly improving the efficiency of on-site installation and daily maintenance.
High Reliability	Adopts high-quality raw materials and industrial-grade components with a robust integrated structure, capable of adapting to harsh industrial operation environments and resisting temperature changes, vibration and electromagnetic interference.
Fault Protection Mechanism	Built with advanced circuits and intelligent protection mechanisms, which can quickly detect, locate and eliminate electrical faults, effectively preventing system damage and reducing unplanned downtime.
User-friendly Design	Optimized for system compatibility and operability, it can be seamlessly integrated into existing control systems and supports rapid equipment upgrade and replacement.
Flexible Application	Applicable to a variety of industrial control scenarios, maintaining stable high performance and operational reliability under different working conditions.

5. Application Fields

Application Field	Description
Turbine Control System	Specially developed and adapted for Mark V SPEEDTRONIC turbine control system
Steam Turbine Equipment	Used for automatic management and operational control of steam turbine units
Gas Turbine Equipment	Applied to automatic regulation and control of gas turbine automation devices
Power Industry	Suitable for high-reliability operation scenarios in power generation, petrochemical, metallurgy and other industries
Industrial Automation	Responsible for safety protection and operational management of industrial control systems
Excitation System	Compatible with and applicable to EX2000 excitation system
Wind Power Generation	Adaptable to control and protection scenarios in the wind power industry
Petroleum Energy Industry	Widely used in control system supporting scenarios of petroleum energy equipment

6. Installation and Maintenance

6.1 Installation Precautions

Mark the connection position of each signal line during installation to avoid equipment downtime caused by wrong wiring.
Fix the PCB board to the internal rack of the drive device through the four corner mounting holes.
Part of the terminal block is a detachable connector structure, which facilitates on-site wiring and wiring adjustment operations.

6.2 Maintenance Key Points

All installation, operation and maintenance operations shall be implemented in strict accordance with the official product manual for detailed specifications.
Regularly inspect the integrity of the on-board wear-resistant protective coating to avoid component aging and damage caused by coating failure.
Check the connection firmness of JJR, JJT and JJS connectors regularly to ensure stable signal transmission.
Verify the jumper settings periodically to ensure the normal operation of the standard buzzer function.

6.3 Product Notes

This product belongs to legacy industrial equipment, and some of its functions have been outdated for modern industrial control demands.
It is recommended to refer to GE official documents to obtain the latest accurate technical parameters and detailed operation specifications.
Second-hand spare parts of this product are available in the market, and users need to strictly verify the version compatibility before purchase and use.

————————————————————————————————————-
