Eaton CDH364NWKX

1. Overview

2. Key Specifications

3. Product Features

• High Efficiency: Adopts high-quality permanent magnets and low-loss windings to achieve high efficiency and low heat generation.
• Wide Voltage Range: Multiple rated voltage options (24 V, 48 V, 110 V, etc.) are available for easy system integration.
• Compact Structure: The closed housing occupies little space, facilitating installation in confined areas.
• Versatile Control Modes: Supports PWM speed regulation and current loop control, compatible with common drives (such as Eaton DR series, Siemens SINAMICS, etc.).
• Reliability: Dust and water-resistant design, with self-lubricating or oil-sealed bearings, suitable for long-term continuous operation.

4. Structure and Composition

• Stator: Copper windings made of high-conductivity enameled wire.
• Rotor: Combination of permanent magnets (rare earth magnets) and steel core, providing strong magnetic flux.
• Bearings: Typically deep groove ball bearings (self-lubricating or oil-sealed optional) to support high-speed operation.
• End Covers/Flange: Provide mechanical fixing points, allowing direct threaded installation or flange connection.
• Terminal Blocks: Protective junction box with dust and water-resistant design.

5. Typical Application Areas

• Conveyor Belts and Handling Systems: Require stable and adjustable speed drives.
• Packaging Machinery: Demand high-speed rotation and precise positioning.
• Printing Equipment: Have strict requirements for speed stability.
• Automated Production Lines: Cooperate with PLCs and frequency converters to achieve flexible control.

6. Installation and Maintenance Guidelines

Pre-Installation Inspection

• Confirm that the motor model, rated voltage, and power match the system requirements.
• Check if the flange hole positions and bolt sizes meet on-site assembly requirements.

Mechanical Installation

• Use ISO 2768-1 tolerance standard for positioning.
• Apply a torque of 30 Nm to the bolts (refer to the actual bolt specifications for details).
• For base mounting, install vibration isolation pads between the base and the motor housing to reduce resonance.

Electrical Wiring

• Connect to PWM or DC power supply according to the Eaton CDH series wiring diagram.
• Use waterproof junction boxes for terminal blocks to ensure the IP rating is not compromised.

Commissioning

• First, perform low-speed no-load operation to check axial and radial clearances, ensuring no abnormal noise or vibration.
• Gradually increase the speed to the rated value, monitoring current and temperature to ensure they are within the rated range.

Routine Maintenance

• Inspect the bearing lubrication status every 2000 hours (or every 6 months), and replace or add grease if necessary.
• Clean dust on the housing surface to maintain unobstructed heat dissipation channels.
• Regularly measure insulation resistance to prevent short circuits caused by insulation aging.
