Eaton LD3600WK Circuit Breaker
Eaton LD3600WK
The LD3600WK is a Molded Case Circuit Breaker (MCCB) from Eaton’s product lineup. It features a rated current of 600 A, 3-pole configuration, and a rated voltage of 600 VAC (alternating current) / 250 VDC (direct current). It is designed for short-circuit protection and overload protection in applications such as distribution boards and industrial control cabinets.
Key Technical Specifications
- Rated Current: 600 A
- Pole Configuration: 3-pole
- Rated Voltage: 600 VAC (AC) / 250 VDC (DC)
- Rated Short-Circuit Breaking Capacity: 50 kA in compliance with IEC 60947-2 standard
- Terminal Type: Standard terminals (2 TA603 LDK) and optional 4 TA603 LDK terminals, supporting multiple wiring methods
- Dimensions: Approximately L 85 mm × W 37 mm × H 85 mm (including base), weight about 7 kg
Product Features
- High Breaking Capacity: Adopts a molded case structure to quickly and reliably break circuits during high-current short circuits.
- Compact and Reliable: Smaller in size and lighter in weight compared to traditional air circuit breakers, facilitating installation in space-constrained distribution cabinets.
- Multiple Terminal Options: Offers standard terminals and optional widened terminals to meet different cable cross-sections and wiring requirements.
- Compliance with International Standards: Meets safety and performance standards such as IEC 60947-2 and UL 489, suitable for global markets.
- Easy Maintenance: Modular design enables convenient disassembly and assembly, reducing inspection and replacement time.
Structure and Composition
- Enclosure: High-strength molded material providing insulation and mechanical protection.
- Contact System: 3-pole breaking structure with high-conductivity copper alloy contacts ensuring low contact resistance.
- Thermal Trip Mechanism: Bimetallic strip thermal trip for overload protection.
- Magnetic Trip Mechanism: Electromagnetic trip realizing instantaneous short-circuit breaking.
- Terminal Block: Standard 2 TA603 LDK terminal block, optional 4 TA603 LDK widened terminal block, supporting 4 mm² – 35 mm² cables.
Typical Application Areas
- Industrial power distribution systems (large loads such as motors, pumps, and compressors)
- Main distribution cabinets in large buildings
- Energy and power facilities (substations, distribution networks)
- Power protection for process control and automation systems
Installation and Maintenance Guidelines
- Installation Dimensions: Ensure the reserved installation space in the cabinet complies with the dimensions specified in the technical manual (L 85 mm × W 37 mm × H 85 mm).
- Wiring: Use terminal blocks that meet specifications, and strictly wire according to phase sequence and polarity to avoid phase-to-phase short circuits.
- Fastening: Use the specified torque value for bolts to prevent loosening caused by vibration.
- Inspection: Regularly check contact wear, spring tension of the trip mechanism, and the fastening status of terminal blocks.
- Replacement: In case of tripping caused by overload or short circuit, first identify the fault cause, then replace the corresponding contacts or trip components, and ensure functional testing before restoration.
————————————————————————————————————-
