Eaton SVX030A1-4A1B1 Svx9000

Product Positioning: A compact, modular industrial variable frequency drive (VFD) in the SVX9000 series, suitable for low-to-medium power variable speed drive applications.Key Advantages: Small size, wide voltage range, and modular design for quick selection and on-site upgrades.

Confirmed Key Specifications

• Rated Current: 46 A
• Rated Voltage Range: 380 ~ 500 V (Three-phase)
• Rated Power: 30 HP (approximately 22 kW)
• Frequency Range: 0 ~ 320 Hz (General for SVX9000 series)
• Input/Output Power Factor: ≥ 0.95 (Typical)
• Overload Capacity: 150% (1 min)

Product Features

• Modular Structure: Drive, control, and power modules can be replaced independently for convenient maintenance.
• Wide Voltage Compatibility: Single unit can switch freely between 380-500 V, adapting to power grids in multiple regions.
• High Efficiency: Adopts the latest IGBT technology with an overall efficiency of ≥ 96%.
• User-Friendly Operation Interface: Color LCD keypad supporting local parameter editing and remote monitoring.
• Multiple Protections: Comprehensive safety protection against overcurrent, overvoltage, short circuit, overtemperature, undervoltage, etc.

Structure and Composition

• Power Module: IGBT stack, heat sink, input filter.
• Control Unit: DSP/microprocessor, communication interfaces (Modbus-TCP, Profibus, EtherNet/IP).
• Chassis and Heat Dissipation: Metal enclosed chassis with optional internal forced air cooling or water cooling.
• Power Supply and Accessories: External 24 V DC control power supply, terminal block, mounting bracket.

Typical Application Fields

• Spindle drive of machining centers
• Speed control of conveyors, fans, and pumps
• Packaging machinery, printing machines, textile equipment
• Variable frequency speed regulation for small and medium-sized automated production lines

Installation and Maintenance

• Installation Points: Ensure the chassis is level, reserve sufficient heat dissipation space, and prevent incorrect connection of terminals.
• Wiring Guide: Three-phase input wiring, power module grounding, and control power supply wiring diagram.
• Commissioning Steps: Parameter initialization → On-site load testing → Operation monitoring and recording.
• Maintenance Recommendations: Regularly inspect cooling fans, clean dust inside the chassis, and use the built-in fault log for preventive maintenance.

————————————————————————————————————-
