GE 117T6409P040ABAC

1. Overview

2. Technical Parameters

3. Product Features

• Automatic Temperature Compensation: Built-in Pt1000 temperature sensor enables accurate automatic temperature compensation for measurement results.
• Gel Electrolyte System: Adopts a gel reference system with no need for repeated refilling, greatly simplifying daily maintenance.
• Dual Ceramic Diaphragm Design: Equipped with two ceramic diaphragms to deliver stable reference potential and ensure consistent measurement accuracy.
• Low Maintenance Cost: Features a non-replaceable gel reference and ceramic pin contact structure, reducing long-term maintenance and replacement costs.
• Robust and Durable: Built with a polycarbonate outer shell and durable handle, adapting to various complex measurement environments.
• Integrated Connection Design: Combined BNC and banana plug design for fast and convenient connection with measuring instruments.

4. Structure and Composition

• Measuring Electrode: pH glass electrode, used to sense the pH value of liquid solutions.
• Reference Electrode: Gel reference system, providing a stable potential reference for accurate measurement.
• Ceramic Diaphragm: Dual ceramic diaphragms serving as stable reference contacts.
• Temperature Sensor: Integrated high-precision Pt1000 temperature sensor.
• Cable and Connector: 2-meter dedicated cable with BNC plug and 4mm banana plug.
• Outer Shell Material: PSU (Polysulfone) electrode shaft and high-strength polycarbonate outer shell.

5. Application Fields

• Drinking Water Testing: Precise pH measurement for drinking water quality inspection.
• Swimming Pool Monitoring: pH detection for swimming pool water treatment and maintenance.
• Aquarium Water Quality Monitoring: Real-time water quality pH detection for aquariums and fish tanks.
• General Aqueous Solution Measurement: Suitable for laboratory and on-site pH testing of various aqueous solutions.
• Environmental Monitoring: Compatible with portable instruments such as Greisinger GMH 5530 for field environmental water quality monitoring.
• Industrial Process Control: Applied to conventional industrial online and offline pH monitoring processes.

6. Installation and Maintenance

6.1 Installation Instructions

• Connect the BNC plug to the pH input interface of the pH measuring instrument.
• Connect the banana plug to the temperature measurement interface (if temperature compensation is required).
• Fasten the PG 13.5 cable thread coupling to ensure stable and sealed connection.
• Calibrate the electrode before use; two-point calibration is recommended for optimal accuracy.

6.2 Maintenance Guidelines

• Regular Calibration: Calibrate the electrode regularly with standard buffer solutions to guarantee measurement precision.
• Cleaning and Storage: Thoroughly clean the electrode after use and store it in a professional preservation solution.
• Pollution Prevention: Clean the electrode timely after measurement to avoid residual contaminants affecting test results.
• Diaphragm Protection: Protect the ceramic diaphragms from damage and keep them intact for stable performance.
• Service Life Management: The electrode can serve for more than 2 years with standardized daily maintenance.
• Special Cleaning: After measuring protein-containing solutions, clean the electrode with a special detergent (e.g., GRL 100 pepsin cleaning solution) to remove protein residues.
