1. Overview

2. Technical Parameters

• Engine: Perkins 1106C-E66TAG2 (GE 145) / 1106C-E66TAG3 (GE 165)
• Alternator Type: Brushless Synchronous Alternator
• Power Output: GE 145 Model – Maximum 121.6 kW (Approx. 166 kVA)
• Voltage/Frequency: 400 V / 50 Hz
• Fuel System: Equipped with a 230L fuel tank, which can support approximately 9.5 hours of continuous operation for the GE 145 model under rated working conditions
• Dimensions & Weight:
  • Dimensions: Approx. 3000mm (L) x 1200mm (W) x 1800mm (H)
  • Weight: Approx. 2130 kg (PS-PMS Model)

______________________________________________________________________________________________

3. Product Features

• High Reliability: Adopts the proven engine technology of Perkins, guaranteeing long-term stable operation and minimizing downtime, which is critical for continuous power supply in key scenarios.
• Modular Design: The product adopts a combined structure of base, fuel tank, and engine/alternator unit, which simplifies transportation, handling, and on-site installation, greatly improving deployment efficiency.
• Safety & Protection: Complies with the UNI EN ISO 9001:2008 quality management system standards, and is equipped with multiple safety protection functions including short-circuit protection and overload protection to ensure safe and stable operation of the unit.
• Automatic Control: Select models are fitted with an EP6 user interface or equivalent control panel, enabling real-time monitoring of engine and generator set operating status, as well as convenient one-key operation and fault alarm functions.

______________________________________________________________________________________________

4. Structure & Components

• Engine Unit: High-performance Perkins diesel engine, delivering stable power output and excellent fuel efficiency.
• Alternator Unit: Synchronous alternator directly connected to the engine shaft, ensuring efficient power conversion and stable voltage output.
• Fuel Tank: Large-capacity integrated fuel tank, providing sufficient fuel reserve for extended continuous operation without frequent refueling.
• Base/Frame: Sturdy mechanical structure that supports the entire generator set, enhancing overall stability and shock resistance during operation.
• Control Panel: Centralized control terminal for starting, stopping, and real-time monitoring of the generator set’s operating parameters and fault status.

______________________________________________________________________________________________

5. Application Fields

• Industrial Applications: Backup power supply for factories and manufacturing facilities to avoid production interruptions caused by power outages.
• Commercial Buildings: Emergency power support for office buildings, shopping malls, and large commercial complexes to maintain normal business operations.
• Data Centers: Backup power for uninterruptible power supply (UPS) systems, ensuring continuous and stable operation of data center equipment and preventing data loss.
• Construction Sites: Temporary power supply for construction sites, meeting the power demand of various construction machinery and on-site facilities.
• Hospitals & Public Facilities: Emergency power for critical public facilities such as hospitals, ensuring the normal operation of life-saving equipment and public service systems.
