1. Product Overview

2. Core Parameters

3. Product Features

• High Reliability: Equipped with an industrial-grade microprocessor and multi-fuse protection design, ensuring stable and reliable operation under critical working conditions to fulfill safety protection requirements without failure.
• Easy Maintenance: No re-welding is required during board replacement. Users only need to transfer the PROM modules from the old board to the new one, which retains the original firmware settings and avoids complex reconfiguration and reprogramming, greatly reducing maintenance time and costs.
• Compact Design: Customized to fit the P Core card slot, featuring a plug-and-play structure that facilitates quick insertion/removal and on-site replacement, adapting to emergency maintenance scenarios in industrial sites.

______________________________________________________________________________________________

4. Structure and Composition

• Microprocessor Module: Adopts the Intel 80196 microprocessor, the core computing unit of the board, responsible for real-time signal monitoring, data calculation and logic judgment of safety parameters.
• Jumpers and Fuses: Berg jumpers are used for board positioning and functional configuration, while multiple fuses provide effective circuit protection, preventing damage to the board caused by overload or short circuit.
• Bayonet Connectors: Standard bayonet connection design, used to connect the main power supply and signal transmission lines of the control system, ensuring stable signal transmission and secure power connection.
• PROM Storage Modules: Stores core trip logic, operating parameters and firmware programs, ensuring the stability and consistency of the board’s safety control functions.

______________________________________________________________________________________________

5. Application Fields

• Aerospace: Applied to the emergency safety protection systems of large aero-engines, ensuring the safe operation of aerospace power equipment.
• Power Plants: Deployed in the safety control systems of gas turbine power plants, undertaking core safety protection tasks for power generation equipment.
• Industrial Gas Turbines: Used in high-pressure gas compression and transmission scenarios in petroleum, chemical and other heavy industries, guaranteeing the operational safety of industrial gas turbine equipment.

______________________________________________________________________________________________

6. Installation and Maintenance

• Installation Location: The board is installed in the P Core of the GE Speedtronic Mark V gas turbine control system, and positioning programming must be completed via Berg jumpers before formal operation to match the system configuration.
• Replacement Process: When replacing the faulty board, it is recommended to remove the PROM modules from the old board and install them on the new replacement board. This operation avoids re-burning firmware and maintains consistent original system parameters, ensuring rapid restoration of equipment operation.
• Troubleshooting: The board is equipped with multiple fuses and jumper components. For fault diagnosis, inspect the fuses for blown status, check whether the jumpers are disconnected or loose, and verify the integrity of PROM modules to locate and resolve faults efficiently.
