1. Core Overview

2. Main Parameters

• Rated Voltage: 500V – 660V (commonly applied on the generator set and transformer sides)
• Control Mode: Adopts Fanuc logic controllers (such as the 752DTX350 series) for digital control
• Protection Grade: IP40 or higher (subject to specific product models)
• Power Capacity: Supports the control of high-power generator sets (e.g., those above 30MW)

______________________________________________________________________________________________

3. Product Features

• Modular Design: Built with a modular structure, which facilitates on-site installation, commissioning and maintenance. All modules support hot swapping for flexible replacement.
• High Reliability: Equipped with advanced self-diagnosis functions, enabling real-time monitoring of internal operating status and effectively reducing equipment failure rates.
• Powerful Control Capability: Integrated with high-performance Fanuc series logic controllers, supporting complex control logics and automated dispatching operations to meet diverse power control demands.

______________________________________________________________________________________________

4. Structure and Composition

• Control Cabinet Body: Built-in Fanuc logic controllers (such as the 752DTX350 series) as the core control component.
• Module Components: Includes core functional modules such as Circuit Breaker Module and Current Transformer Module, undertaking key power control and monitoring tasks.
• Accessories: May be equipped with relays, transformers and auxiliary circuit boards for status monitoring and precise control, ensuring the stable operation of the entire system.

______________________________________________________________________________________________

5. Typical Application Fields

• Power Plants: Applied to the automatic control, grid-connected dispatching and operation protection of generator sets.
• Substations: Serves as an automatic device on the power grid side, responsible for voltage regulation and load distribution to maintain grid stability.
• Large Industrial and Mining Enterprises: Widely used in industrial scenarios requiring high-reliability power control, ensuring the stability of industrial power supply and operation.

______________________________________________________________________________________________

6. Installation and Maintenance

• Installation: On-site installation must be carried out by professional electrical engineers, and wiring needs to be coordinated with other GE Fanuc series equipment to ensure system compatibility and operational safety.
• Maintenance: Supports hot swapping, allowing single module replacement without shutting down the entire system, greatly reducing system downtime. Routine maintenance includes checking wiring tightness, cleaning dust, and updating control logic programs to keep the equipment in optimal operating condition.
