GE CR306E002LAA Magnetic Starter
GE CR306E002LAA
The GE CR306E002LAA is a 90A 3-Pole Magnetic Starter manufactured by General Electric (GE). This model is typically used for motor starting, overload protection, and motor forward/reverse control, and is widely applied in industrial automation and power control systems.
______________________________________________________________________________________________
Key Parameters & Technical Specifications
|
Parameter
|
Description
|
|---|---|
|
Rated Current
|
90A
|
|
Number of Poles
|
3-Pole (for three-phase motors)
|
|
Voltage
|
115/120V (single-phase control circuit)
|
|
Phase
|
1-Phase (control side), 3-Phase (load side)
|
|
Applicable Power
|
Suitable for starting high-power three-phase motors
|
|
Control Method
|
Magnetic starting (with overload relay)
|
|
Frequency
|
60Hz
|
|
Rated Power
|
10kW (reference value, subject to specific applications)
|
______________________________________________________________________________________________
Product Features
- High Reliability: Adopts advanced magnetic control technology from General Electric (GE), ensuring safe and stable operation during motor starting and running.
- Overload Protection: Built-in overload relay automatically cuts off the circuit when the motor operating current exceeds the preset threshold, preventing motor damage.
- Compact Structure: Small in size, easy to install in electrical control cabinets and saves installation space.
- Easy Maintenance: Modular design enables convenient troubleshooting and component replacement.
______________________________________________________________________________________________
Structure & Components
The GE CR306E002LAA generally consists of the following components:
- Power Contacts: Responsible for connecting and disconnecting the main circuit current.
- Magnetic Coil: Controls the opening and closing of the contacts.
- Overload Relay: Provides overload protection for the motor.
- Auxiliary Contacts: Used for signal output of the control circuit.
- Enclosure: Normally made of plastic or metal with excellent insulation properties.
______________________________________________________________________________________________
Typical Applications
- Industrial Automation: Controls the starting and stopping of large industrial motors.
- Water Pump Systems: Manages high-power water pumps in water treatment plants and building water supply systems.
- HVAC Systems: Controls fans in large heating, ventilation and air conditioning systems.
- Mining Machinery: Operates mine ventilators and conveyor belt motors.
- Other Heavy Machinery: Drives equipment requiring high starting current, such as compressors and rolling mills.
______________________________________________________________________________________________
Installation & Maintenance Recommendations
- Wiring Requirements: Strictly follow the electrical drawings during wiring to ensure correct power phase sequence. Distinguish wiring for the main circuit and control circuit carefully.
- Grounding: Proper grounding is mandatory during installation to prevent electric leakage caused by insulation damage.
- Overload Relay Calibration: Adjust the trip current of the overload relay according to the motor’s rated current, usually set to 115%-125% of the rated current.
- Regular Inspection: Check contact wear regularly, and clean or replace worn parts as needed.
- Environmental Requirements: Avoid installation in environments with corrosive gases, excessive dust or extremely high temperatures.
————————————————————————————————————-
