GE CR463MD0NJA10A Large Electromagnetic Contactor
GE CR463MD0NJA10A
GE CR463MD0NJA10A is a large electromagnetic contactor produced by General Electric (GE), mainly used to control high-power motors and large electrical loads. This model belongs to GE’s Heavy Duty Contactors series and is commonly found in industrial electrical distribution cabinets.
______________________________________________________________________________________________
The following is a detailed introduction to the product:
1. Overview and Main Functions
- Product Positioning: Belongs to GE’s Heavy Duty Contactors series (Model CR463), designed specifically for heavy-duty loads such as high-power motors, water pumps, and compressors.
- Core Functions: Used to connect or disconnect the main power circuit in the control circuit, capable of withstanding high current impacts and protecting the safe operation of motors and circuits.
- Applicable Standards: Complies with IEC 60947-4-1 standard, providing reliable electrical isolation and control functions.
______________________________________________________________________________________________
2. Key Technical Parameters
|
Parameter
|
Specification/Description
|
|---|---|
|
Rated Voltage
|
277 VAC
|
|
Rated Current
|
30A
|
|
Number of Phases
|
3 Phases
|
|
Number of Poles
|
2 Poles
|
|
Model Suffix Meaning
|
NJA10A indicates a specific contact configuration and additional functions, usually related to contact capacity or specific characteristics of auxiliary contacts.
|
|
Protection Class
|
NEMA 1 (for indoor use)
|
______________________________________________________________________________________________
3. Product Features
- High Durability: Adopts high-quality coil and contact materials, resistant to high temperature and corrosion, with a long service life.
- Strong Impact Resistance: Capable of withstanding large current impacts generated during motor startup.
- High Reliability: Sturdy structure and stable contact pressure ensure low-resistance contact.
______________________________________________________________________________________________
4. Structure and Composition
- Main Contacts: Responsible for connecting or disconnecting the main circuit.
- Auxiliary Contacts: Provide additional signal feedback functions (such as normally open and normally closed contacts).
- Coil: Generates a magnetic field to drive contact action when energized.
- Enclosure: The metal enclosure protects internal components, usually NEMA 1 class, suitable for indoor use.
______________________________________________________________________________________________
5. Application Fields
- Industrial Power Distribution: Used to control heavy-duty equipment such as large motors, transformers, and water pumps.
- Power System: Serves as the core circuit breaking component in distribution cabinets.
- Automation Control: Acts as an executive component in PLC control systems.
______________________________________________________________________________________________
6. Installation and Maintenance
- Installation: Usually installed in distribution cabinets and fixed with bolts. When wiring, pay attention to distinguishing the terminals of main contacts and auxiliary contacts.
- Maintenance: Regularly check the contact wear, clean dust, and inspect the coil insulation resistance to ensure the reliable operation of the contactor.
————————————————————————————————————-
