GE IM0076D Servo Electric Cylinder
GE IM0076D
GE IM0076D is a high-precision servo electric cylinder, mainly used to replace hydraulic cylinders and air cylinders, realizing environmentally friendly, high-precision and low-maintenance linear motion control. This model belongs to the GE series electric cylinders, featuring a compact structure and high rigidity, suitable for various industrial automation scenarios.
______________________________________________________________________________________________
1. Core Parameters
- Thrust Capacity: Usually between 1000N and 5000N (specific value depends on the specific configuration).
- Stroke Range: The minimum stroke is about 50mm, and the maximum stroke can reach 300mm or longer.
- Accuracy: Positioning accuracy can reach 0.01mm level.
- Speed: Supports high-speed movement, with a peak speed usually up to 2m/s or higher.
- Feedback Device: Built-in multi-turn absolute encoder to provide real-time position feedback.
______________________________________________________________________________________________
2. Product Features
- High-Precision Closed-Loop Control: Achieves extremely high positioning accuracy and repeat positioning accuracy through servo motors and encoders.
- Low Noise and Low Pollution: No risk of hydraulic oil leakage, low operating noise, suitable for clean rooms and places with high environmental protection requirements.
- High Rigidity and Impact Resistance: Compact structure, strong rigidity, strong impact resistance and long service life.
- Easy Maintenance: Simple structure, no wearing parts, low maintenance cost, usually only regular greasing is required.
______________________________________________________________________________________________
3. Structure and Composition
- Electric Cylinder Body: Aluminum alloy or steel material, with ball screw inside.
- Servo Motor: Drive motor, responsible for providing power.
- Reduction Device: Planetary reducer or worm gear reducer, which reduces speed and amplifies torque.
- Lead Screw and Nut: Convert rotary motion into linear motion.
- Position Feedback Device: Multi-turn absolute encoder for accurately feeding back position information.
______________________________________________________________________________________________
4. Main Application Fields
- Industrial Automation: Robotic arms, CNC machine tools, packaging machinery.
- Paper Making and Chemical Industry: Used for web tension control and roller movement.
- Automobile Manufacturing: Assembly line automation, punch press control.
- Electronic Manufacturing: Precision assembly, placement machines.
______________________________________________________________________________________________
5. Installation and Maintenance
Installation Methods
- Front Flange/Rear Flange: Installed on the equipment frame through flanges.
- Side Flange: Suitable for lateral push rod installation.
- Tail Hinge: Suitable for occasions with limited space.
Maintenance Points
- Lubrication: Regularly check and supplement grease to prevent wear of the ball screw.
- Seal Inspection: Ensure the sealing ring is intact to prevent external contaminants from entering.
- Connection Inspection: Check whether the connection between the motor and the controller is firm to prevent signal loss.
————————————————————————————————————-
