GE DS200FCGDH1BBA Status Card

Short Description:

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: General Electric

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-18250705533

( WhatsApp )Wechat: + 86-18250705533

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

GE DS200FCGDH1BBA

1. Overview

The GE DS200FCGDH1BBA is a gate control distribution and status card developed by General Electric (GE) for the Mark VI / Mark V series Speedtronic control systems. It is primarily deployed in power plants, substations, and other power industrial scenarios. Receiving SCR firing data from the DSPC card, this module realizes precise control and real-time status monitoring of power electronic equipment, including gates, valves, and pumps. As a core component of GE’s DCS and excitation control systems, it features high operational reliability, standardized modular design, and high-precision control performance.

2. Main Technical Parameters

Parameter Item	Specification Value
Manufacturer	General Electric (GE)
Product Series	Mark VI / Mark V (Speedtronic Control System)
Channel Quantity	12 Channels
Measurement Range	-8 mV to +45 mV
Operating Voltage	24 V DC
Operating Temperature Range	-30℃ to 65℃
Circuit Board Dimensions	9.2 × 6.3 Inches
Weight	Approx. 0.45 kg
Installation Method	DIN Rail Mounting

3. Product Features

High Reliability: Capable of stable and continuous operation in harsh and high-demand industrial environments.
Modular Design: Adopts standard DIN rail mounting structure, supporting flexible system expansion and convenient daily maintenance.
Precise Control Performance: Equipped with speed estimation technology and closed-loop speed control algorithm to achieve rapid response and accurate regulation.
High Starting Torque: The starting torque can reach more than 150% at 1Hz, ensuring reliable startup under heavy-load conditions.
Zero-Frequency Torque Retention: Maintains stable torque output even when the inverter output frequency is zero, optimizing equipment low-speed operation performance.
Multi-parameter Auto-tuning Function: Supports automatic parameter calibration, simplifying user debugging and parameter adjustment operations.
Ground Fault Handling Capability: Eliminates ground faults without interrupting system operation, significantly improving operational continuity and system stability during fault periods.

4. Structure and Composition

The DS200FCGDH1BBA is a dedicated GE gate control distribution and status card, specially designed for automatic control and status monitoring of industrial equipment such as gates, valves, and pumps.

In terms of physical structure, the module adopts a standard DIN rail mounting design, with a circuit board size of 9.2 × 6.3 inches and a net weight of approximately 0.45 kg. It operates by receiving and analyzing SCR firing data transmitted from the DSPC control card, realizing systematic and intelligent equipment control.

5. Application Fields

The DS200FCGDH1BBA card is widely used in various industrial automation and process control fields, with typical application scenarios as follows:

Power generation and power industry
Substation systems (excitation control, compatible with Mark VI, Mark VIe and EX2100 excitation controllers for seamless interface)
Petroleum and natural gas industry
Chemical industry
Water treatment engineering
Pharmaceutical manufacturing
General manufacturing industry

6. Installation and Maintenance

6.1 Installation Requirements

This product adopts standard DIN rail mounting. As a dedicated plug-in card for the Mark VI Speedtronic control system, it needs to be installed and configured as an internal component of the complete control system in accordance with system assembly specifications.

6.2 Maintenance Specifications

All application operations must comply with the official product manual and be carried out within the specified operating temperature and working conditions. Avoid using the module in environments with high temperature, high humidity, corrosive gas or severe vibration. Unauthorized modification, disassembly or repair of the module is prohibited to prevent system failure and equipment damage.

————————————————————————————————————-

If you would like to learn more about our products and services, please feel free to contact us at any time!
